Hino Truck 2016 COE HEV Service Manual Workshop Guide

Format: PDF Language: English Hino 2016 COE HEV Truck Manual for 155, 155h, 195, 195h Series – 857 Pages Hino 2016 COE HEV Troubleshooting Manual – 871 Pages Hino J05E Engine Manual – 653 Pages Description Hino Truck 2016 COE HEV Service Manual This is the Repair and Service Manual for Hino Truck 2016 COE HEV Applicable for HINO 155, 155h, 195, 195h series, Format: PDF Language: English Hino 2016 COE HEV Truck Manual for 155, 155h, 195, 195h Series – 857 Pages Hino 2016 COE HEV Troubleshooting Manual – 871 Pages Hino J05E Engine Manual – 653 Pages This workshop manual has been prepared to provide information covering repairs on 155, 155h, 195, 195h Series Hino 2016 COE HEV trucks. To use Hino Year 2016 and Series 155, 155h, 195, 195h Conventional trucks for years, smoothly, safely, and economically without trouble, it is important to perform inspections. Maintenance required to be performed is the responsibility of the owner. Some recommended repairs of your truck are mentioned. When making any repair of your truck, be careful not to be injured through improper procedures. As for maintenance items, refer to the Owners and Drivers Manual. All information and specifications in this manual are based upon the latest product information available at the time of printing. Table of Content For Hino 2016 COE HEV Truck Manual: General Introduction Engine Hybrid System Transmission Clutch Propeller Shaft Axle Differential Brake Steering Frame and Frame Accessory Cab Mounting and Cab Suspension Body Construction Suspension Body Inside Accessory Body Outside Accessory Air Bag and Seat Belt Heater and Air Conditioner Electrical Control System Hino Truck 2016 COE HEV Manual Instruction Extract: REPLACEMENT REMOVING THE FRONT FLEXIBLE HOSE 2. REMOVING THE FRONT WHEELS 3. REMOVING THE FLEXIBLE HOSE No.1 (1) Using the union nut wrench (10 mm {0.394 in.}), disconnect the brake tube from the flexible hose No.1. (2) Remove the clip and remove the flexible hose No.1 from the body. (3) Remove the bolt and disconnect the flexible hose No.1 from the bracket. (4) Unfasten the union bolt and gasket (2 pcs.) to remove the flexible hose No.1 from the brake caliper. INSTALLING THE FRONT FLEXIBLE HOSE 1. INSTALLING THE FLEXIBLE HOSE No.1 (1) Install the flexible hose No.1 to the bracket with a new clip. (2) Using the union nut wrench (10 mm {0.394 in.}), connect the brake tube to the flexible hose No.1. Tightening Torque: 15 Nm {153 kgfcm, 11 lbfft} ! CAUTION • Install in a way that the twist of the flexible hose is minimum. • Install the clip certainly to the end. (3) Connect the flexible hose No.1 to the brake caliper with the union bolt and new gasket (2 pcs.). Tightening Torque: 31 Nm {316 kgfcm, 23 lbfft} (4) Install the flexible hose No.1 to the bracket with a bolt. Tightening Torque: 28 Nm {286 kgfcm, 21 lbfft} 2. BLEEDING AIR FROM THE BRAKE SYSTEM Reference: BRAKE, BRAKE CONTROL, BRAKE FLUID, REPLACEMENT, CHANGING THE BRAKE FLUID (Page 9-20) 3. INSTALLING THE FRONT WHEELS Tightening Torque: 440-590 Nm {4,500-6,000 kgfcm, 325-435 lbfft}
