Hino Truck 2017 COE HEV Service Manual Workshop Guide

Format: PDF Language: English Hino 2017 COE HEV Truck Manual for 155, 155h, 195, 195h Series – 842 Pages Hino 2017 Owners Manual – 354 Pages Troubleshooting Manual for Hino 2017 COE HEV – 860 Pages Hino J05E Engine Manual – 648 Pages Description Hino Truck 2017 COE HEV Service Manual This is the Repair and Service Manual for Hino Truck 2017 COE HEV Applicable for HINO 155, 155h, 195, 195h series, Format: PDF Language: English Hino 2017 COE HEV Truck Manual for 155, 155h, 195, 195h Series – 842 Pages Hino 2017 Owners Manual – 354 Pages Troubleshooting Manual for Hino 2017 COE HEV – 860 Pages Hino J05E Engine Manual – 648 Pages This workshop manual has been prepared to provide information covering repairs on 155, 155h, 195, 195h Series Hino 2017 COE HEV trucks. To use Hino Year 2017 and Series 155, 155h, 195, 195h Conventional trucks for years, smoothly, safely, and economically without trouble, it is important to perform inspections. Maintenance required to be performed is the responsibility of the owner. Some recommended repairs of your truck are mentioned. When making any repair of your truck, be careful not to be injured through improper procedures. As for maintenance items, refer to the Owners and Drivers Manual. All information and specifications in this manual are based upon the latest product information available at the time of printing. Table of Content For Hino 2017 COE HEV Truck Manual: General Introduction Engine Hybrid System Transmission Clutch Propeller Shaft Axle Differential Brake Steering Frame and Frame Accessory Cab Mounting and Cab Suspension Body Construction Suspension Body Inside Accessory Body Outside Accessory Air Bag and Seat Belt Heater and Air Conditioner Electrical Control System Hino Truck 2017 COE HEV Manual Instruction Extract: INSPECTING THE SHOCK ABSORBER 1. INSPECTING THE SHOCK ABSORBER (1) Elongate and contract the shock absorber to inspect for abnormal noise and oil leakage. Make sure the operating load of its stroke is constant in all the range and there is no abnormal interference. NOTICE Press down the shock absorber to the lowest end, then it is left to stretch to its highest position by itself. Repeat the motion 4 or more times. INSTALLING THE SHOCK ABSORBER 1. MOUNTING THE SHOCK ABSORBER BUSHING (1) Mount the new shock absorber bushing to the shock absorber by using the SST and the press. SST: 09222-64012 Connecting rod bushing remover & replacer 09726-10011 Lower suspension arm bushing remover & replacer 2. INSTALLING THE SHOCK ABSORBER (1) Use the bolt to temporary mount the shock absorber upper side to the frame via the cushion No.1 (2 pcs.). (2) Use the bolt to temporary mount the shock absorber lower side via the cushion No.1 (2 pcs.). (3) Fully tighten the both side bolts (2 pcs.). Tightening Torque: 68 Nm {693 kgfcm, 50 lbfft}
