Hino Truck FA4J, FB4J Year 2001 Repair Manual (FA, FB) Workshop Guide

This is the Repair and Service Manual for Hino Truck 2001 Series: FA, FB (FA4J, FB4J) Format: PDF Language: English Hino 2001 Truck FA and FB Series Manual – 1098 Pages Description Hino Truck FA4J, FB4J Year 2001 Repair Manual (FA, FB) This is the Repair and Service Manual for Hino Truck 2001 Series: FA, FB (FA4J, FB4J) Format: PDF Language: English Hino 2001 Truck FA and FB Series Manual – 1098 Pages This workshop manual has been prepared to provide information covering repairs FA, FB series Hino 2001 trucks. To use Hino 2001 trucks for years, smoothly, safely, and economically without trouble, it is important to perform inspections. Maintenance required to be performed is the responsibility of the owner. Some recommended repairs of your truck are mentioned. When making any repair of your truck, be careful not to be injured through improper procedures. As for maintenance items, refer to the Owners and Drivers Manual. All information and specifications in this manual are based upon the latest product information available at the time of printing. Table of Content For Hino FA4J, FB4J Year 2001 Truck Manual: General Introduction Engine Clutch Clutch Control Transmission Transmission Control Propeller Shaft Rear Axle Front Axle Steering Service Brake Parking Brake Exhaust Brake Wheels & Tires Suspension Chassis Frame Cab Electrical Equipment Alternator Starter Compressor Turbocharger Spring Brake Power Steering Automatic Transmission Antilock Brake System Total Electronics System Service Specification Electrical Wiring Diagrams Hino Truck 2001 Manual Instruction Extract: Removing the Steering Wheel 1. Turn the Starter Switch Off. 2. Remove the Covering Plug, Then Loosen the 3. Remove the Horn Button by Hand. 4. Disconnect the Wiring Harness. 5. Remove the Steering Wheel Nut With a 27 Mm Socket Wrench. Before Removing the Steering Wheel From The Shaft, Mark Both So That Their Relative Positions Will Be the Same When Reassembled. Inspection 1. Examine the Steering Wheel for Distortion, Damage or Cracks. Replace It if It Is Found To Be Unsuitable. 2. Examine the Serrated Part in the Center of The Steering Wheel, and if It Is Damaged, Replace Installation 1. Apply Chassis Grease to the Horn Contact Plate on the Lower Side of the Steering Wheel. Chassis Grease: Refer to Recommended Lubricant 2. Install the Steering Wheel. Position the Steering Wheel According to The Mark Made When Disassembling, Then Tighten It on With the Setting Nut. Tightening Torque: 500 – 800 Kgcm (37 – 57 Lbft) 3. Install the Horn Button. 1. After Attaching the Wiring Harness, Match the Legs of The Horn Button to the Retainer Hole and Press It in. 2. Secure the Horn Button Assembly Firmly With the Horn Button Holding Screw, and Replace the Covering Plug. Tightening Torque: 15 – 25 Kgcm (1.1 – 1.8 Lbft)
