Hitachi ZX670LC-5A and ZX690LCH-5A Excavator Service Repair Manual Workshop Guide

This manual is applicable for Hitachi ZX670LC-5A and Hitachi ZX690LCH-5A Language: English Format: PDF Service Repair Manual consists of the following separate Part No. Technical Manual (Operational Principle) : Vol. No.TOJBG-EN Technical Manual (Troubleshooting) : Vol. No.TTJBG-EN Service Repair Manual : Vol. No.WJBG-EN Description Hitachi ZX670LC-5A and ZX690LCH-5A Excavator Service Manual Manual is applicable for ZX670LC-5A and ZX690LCH-5A Language: English Format: PDF Service Manual consists of the following separate Part No. Technical Manual (Operational Principle) : Vol. No.TOJBG-EN (394 Pages) Technical Manual (Troubleshooting) : Vol. No.TTJBG-EN (462 Pages) Service Manual : Vol. No.WJBG-EN (665 Pages) Electrical Circuit Diagram: 21 Pages This manual is written for an experienced technician to provide technical information needed to maintain and repair this machine. The machine specification and description according to destination may be explained on this manual. Hitachi ZX670LC-5A and ZX690LCH-5A Manual Composition This manual consists the Technical Manual, the Workshop Manual and the Service Manual. Information included in the Technical Manual: Technical information needed for redelivery and delivery, operation and activation of all devices and systems, operational performance tests, and troubleshooting procedures. Information included in the Service Manual: Technical information needed for maintenance and repair of the machine, tools and devices needed for maintenance and repair, maintenance standards, and removal / installation and assemble / disassemble procedures. Repair any defects and damage found, such as oil or water leaks, loose bolts, cracks and so on, before starting to test.
