Enhance your understanding and maintenance of the Jaguar E-PACE X540 with our extensive service workshop manual, suitable for models from 2017 onwards. This manual, spanning 15350 pages, is available as a downloadable link.
REFERENCE POWERTRAIN:
Engine Specifications:
Petrol:
1.5 L Ingenium AJ150 I3 (P160 & P300e)
2.0 L Ingenium AJ200 I4
Diesel:
2.0 L Ingenium AJ200D I4 (D165 & D200)
Electric Motor Details:
48V mild-hybrid (Synchronous Reluctance Motor)
80 kW Synchronous Reluctance Motor (PHEV)
Transmission Options:
8-speed Aisin AWF8F35 automatic (P160 & P300e)
9-speed ZF 9HP automatic
Hybrid Drivetrain:
MHEV (P160 / D165 / D200)
PHEV (P300e)
Battery Information:
15 kWh Lithium-ion (PHEV)
This manual is an invaluable resource for Jaguar E-PACE X540 owners, providing detailed insights into vehicle maintenance, repair, and advanced features.
