Kawasaki 70Z-6 Wheel Loader Service Manual

Machinery Type: 70Z-6 Wheel Loader Language English Format: PDF Kawasaki 70Z-6 Wheel Loader Repair Service Manual – 1192 Pages Kawasaki 70Z-6 Wheel Loader Operating (Owners) Manual – 398 Pages Parts Catalog: 559 Pages Description Kawasaki 70Z-6 Wheel Loader Service Manual Machinery Type: 70Z-6 Wheel Loader Language English Format: PDF Kawasaki 70Z-6 Wheel Loader Repair Service Manual – 1192 Pages Kawasaki 70Z-6 Wheel Loader Operating (Owners) Manual – 398 Pages Parts Catalog: 559 Pages Manual Details This manual contains guidelines on repair and maintenance work for the 70Z-6 Loader. All explanations, drawings and photographs are current at the time of going to press. Repair and maintenance work should be carried out systematically and logically after thoroughly reading and understanding this manual to ensure that the shovel loader gives reliable, long-term service. The manual is structured as follows to make it easy to use SHOP SERVICE MANUAL CONTENT: 01 GENERAL OUTLINE 10 FUNCTIONS AND CONSTRUCTION 20 INSPECTION AND ADJUSTMENT 30 DISASSEMBLY AND ASSEMBLY 40 MAINTENANCE STANDARDS The most important maintenance operations are those related to safety. The points that  have special significance from the safety point-of-view are indicated with a A mark in this manual. Manual Extract: Precautions for Inspection and Maintenance 1. Disconnect the power source. Disconnect the harness from the negative terminal side in battery first when taking wire harnesses and connectors off for repair or replacement work. Failure to do so can result in damage to the wire harnesses, fuses and fusible links and, in some cases, cause fire due to short-circuit. In addition, even when the key switch is turned OFF, the controller may be operated for a specified time. Therefore, disconnect the harness from the negative terminal side in battery after setting the key switch to the OFF position and waiting one minute or more. 2. Color coding of wire harnesses. As for the color codes of wire harnesses in the electrical system, refer to the table. In cases on the design sheet where two colors are indicated for one wire, the left initial stands for base color, while the right initial stands for marking color.
