Kawasaki 85ZIV Wheel Loader Repair Service Manual

Machinery Type: 85ZIV or 85Z4 Wheel Loader Language English Format: PDF Kawasaki 85ZIV Wheel Loader Repair Service Manual – 934 Pages Kawasaki 85ZIV Wheel Loader Operating (Owners) Manual – 162 Pages Parts Catalog – 356 Pages Description Kawasaki 85ZIV Wheel Loader Service Manual Machinery Type: 85ZIV or 85Z4 Wheel Loader Language English Format: PDF Kawasaki 85ZIV Wheel Loader Repair Service Manual – 934 Pages Kawasaki 85ZIV Wheel Loader Operating (Owners) Manual – 162 Pages Parts Catalog – 356 Pages Manual Details This manual contains guidelines on repair and maintenance work for the 85ZIV Loader. All explanations, drawings and photographs are current at the time of going to press. Repair and maintenance work should be carried out systematically and logically after thoroughly reading and understanding this manual to ensure that the shovel loader gives reliable, long-term service. The manual is structured as follows to make it easy to use SHOP SERVICE MANUAL CONTENT: 01 GENERAL OUTLINE 10 FUNCTIONS AND CONSTRUCTION 20 INSPECTION AND ADJUSTMENT 30 DISASSEMBLY AND ASSEMBLY 40 MAINTENANCE STANDARDS The most important maintenance operations are those related to safety. The points that  have special significance from the safety point-of-view are indicated with a A mark in this manual. Checking performance of parking brake 1. Steer the machine to the right side. Lower boom and bucket to the ground. Stop the engine. Remove the connector of the electrical line from the parking brake solenoid valve (see the photo) to apply the parking brake. 2. Lower the boom to the lower limit, and roll back the bucket until it contacts the stopper. 3. Set the shift lever to 3rd reverse speed. 4. Gradually increase the engine speed. The machine should not move at the maximum speed. If the machine begins to move with the parking brake applied, the brake shoes are burnt or misadjusted. At the completion of parking brake test, be sure to connect the connector of electrical line to the solenoid valve again
