Kobelco SK100 and SK120 Excavator Service Manual Workshop Guide

Manual Included: Service Manual: Shop Manual: Specifications: Brand: Kobelco Model: SK100, SK120 and SK120LC including Acera Serial Number: SK100 – YW2801 – Up, YW03371 – Up, YW05724 – Up and YW05378 – Up SK120 – LP5201 – Up, LP06191 – Up and LP09850 – Up SK120LC – YP1601 – Up, YP01601 – Up and YP01982 – Up Type: Excavator Manuals: Service Manual and Shop Manual Publication No: S5YPU0005E (Jan 1995), S5LP0008E, S5LP0007E (April 1994), S5LP0004E , S5LP0005E and S5LF0006E Language: English Format: PDF Description TABLE OF CONTENTS SPECIFICATIONS 1 – Outline 2 – Specifications 3 – Attachment dimensions MAINTENANCE 11 – Tools 12 – Standard maintenance time table 13 – Maintenance standards and tests procedures SYSTEM 21- Mechatro Control System 22 – Hydraulic system 23 – Electrical system 24 – Components system 25 – AIR-CONDITIONER SYSTEM DISASSEMBLING 31 – Whole disassembly and assembly 32 – Attachments 33 – Upper structure 34 – Travel system TROUBLESHOOTING 41- Mechatro Control 42- Hydraulic 43- Electrical 44- Engine 21- Engine Preface Instructions Read and understand all Warning plates and decal on the machine before Operating, Maintaining or Repairing this machine. The Manual has been written for the repair specialist. The serviceman or mechanic may be unfamiliar with many of the systems on this machine. This makes it important to use this manual and be caution when performing service work. Please go carefully through the Shop Manual of the Excavator before starting any repair work. Use proper lifting procedures when removing any components. Be careful when removing filler caps, breathers and plugs on the machine. Hold a rag over the cap or plug to prevent being sprayed or splashed by liquids under pressure. The danger is even greater if the machine has just been stopped because fluids can be hot. Use the Manual as a reference book and source of information even if you are familiar with Excavator technology. Using the Manual, the experience construction machine mechanic can carry out any necessary repairs expertly. Sections of the Manual How to Index each Manual section. The General of his Manual consists of 8 heading as shown above. Each section can easily referred to by indexes appended to the margin of the page as indicated on the right. Repair and Parts Carry out any necessary repair work as soon as possible. This reduces repair costs and increases the availability of your Excavator. When doing any work on the Excavator, always observe the instructions given in the Manual. Do not operate this machine unless you have read and understand the instructions in the Manual. Improper machine operation is dangerous and could result in injury or death.
