Kobelco SK210LC, SK250LC Excavator Service Manual Workshop Guide

Manual Included: Service Manual: 1052 Pages Specifications: Brand: Kobelco Model: SK210LC, SK250LC Serial Numbers: YQ07U0101- (SK210LC) LL08U0101- (SK250LC) Type: Hydraulic Excavator Manuals: Service Manual Publication Numbers: S5YQ/LL12E-00 Language: English Format: PDF Description TABLE OF CONTENT : Service manual Section 1 – SPECIFICATION Section 2 – MAINTENANCE Section 3 – SYSTEM Section 4 – DISASSEMBLY Section 5 – TROUBLESHOOTING Section 6 – ENGINE Section 7 – MISCELLANEOUS Preface Instructions Read and understand all Warning plates and decal on the machine before Operating, Maintaining or Repairing this machine. The manual has been written for the repair specialist. The serviceman or mechanic may be unfamiliar with many of the systems on this machine. This makes it important to use this manual and be caution when performing service work. Please go carefully through the Shop Manual of the Excavator before starting any repair work. Use proper lifting procedures when removing any components. Be careful when removing filler caps, breathers and plugs on the machine. Hold a rag over the cap or plug to prevent being sprayed or splashed by liquids under pressure. The danger is even greater if the machine has just been stopped because fluids can be hot. Use the Shop/Service Manual of the SK210LC, SK250LC Excavator as a reference book and source of information even if you are familiar with Excavator technology. Using the Workshop Manual, the experience construction machine mechanic can carry out any necessary repairs expertly. Sections of the manual How to Index each Service manual section. The General of his Service Manual consists of 8 heading as shown above. Each section can easily referred to by indexes appended to the margin of the page as indicated on the right. REPAIR and Parts Carry out any necessary repair work as soon as possible.This reduces repair costs and increases the availability of your Excavator. When doing any work on the Excavator, always observe the instructions given in the Manual. Do not operate this machine unless you have read and understand the instructions in the SERVICE MANUAL. Improper machine operation is dangerous and could result in injury or death. REFUELING Move the machine to a well ventilated area for refueling. Use only specified fuel as described in the MAINTENANCE section of the manual. Immediately clean up all spilled fuel and dispose of properly. After refueling is complete, securely tighten fuel cap. HYDRAULIC PRESSURE Under normal conditions, all circuits of the hydraulic system are under extreme pressure. When inspecting for leaks, use a small piece of cardboard, wood or metal to locate leaks. SMALL (PINHOLE) LEAKS CAN BE DANGEROUS IF CONTACT WITH SKIN OR EYES IS MADE. Wear approved safety glasses or face shield, gloves, hard hat, safety shoes and work clothes during all inspection and maintenance procedures.
