Komatsu D20PL-7, D20PLL-7, D20AG-7, D20P-7, D20PG-7A Dozer Manual Workshop Guide

Manual Included: Shop Manual: 761 pages Specifications: Brand: Komatsu Model : D20PL-7, D20PLL-7, D20AG-7, D20P-7, D20PG-7A Serial Number: D20PL-7: 62001 and up, D20PLL-7: 62001 and up, D20AG-7: 62001 and up, D20P-7: 75001 and up, D20PG-7A: 75001 and up, D21A-7: 75001 and up, D21AG-7: 75001 and up, D21PG-7A: 75001 and up, D21S-7: 61001 and up, D210G-7: 61001 and up, D21A-7T: 75001 and up Type: Dozer Manuals: Shop Manual Publication Number: SEBM001408 Language: English Format: PDF Description Table of Contents – GENERAL DESCRIPTION – Structure and Functions – Testing and Adjusting – Disassembly and Assembly – Maintenance Standard – Others GENERAL This section lists the general machine dimensions, performance specifications, component weights, and fuel, coolant and lubricant specification charts. STRUCTURE, FUNCTION AND MAINTENANCE STANDARD This section explains the structure and function of each component. It serves not only to give an understanding of the structure, but also serves as reference material for troubleshooting. In addition, this section gives the judgement standards when inspecting disassembled parts. TESTING AND ADJUSTING This section explains checks to be made before and after performing repairs, as well as adjustments to be made at completion of the checks and repairs. DISASSEMBLY AND ASSEMBLY This section explains the order to follow when removing, installing, disassembling or assembling each component, as well as precautions for these operations. STANDARD VALUE TABLE This section explains the standard values for new machine and judgement criteria for testing, adjusting and troubleshooting. This standard value table is used to check the standard values in testing and adjusting and to judge parts in troubleshooting.
