Komatsu PC300LC-6 and PC300HD-6 Excavator Service Manual Workshop Guide

Manual Included: Shop Manual: 786 pages Specifications: Brand: Komatsu Model: PC300LC-6, PC300HD-6 Serial Number: A83001 and up Type: Excavator Manuals: Shop Manual Publication Number: CEBM002901 Language: English Format: PDF Description Table of Contents 00 FORWARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 00-1 01 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01-1 10 STRUCTURE AND FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1 20 TESTING, ADJUSTING AND TROUBLESHOOTING . . . . . . . . . . 20-1 30 DISASSEMBLY AND ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . 30-1 40 MAINTENANCE STANDARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40-1 90 OTHER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90-1 GENERAL This section lists the general machine dimensions, performance specifications, component weights, and fuel, coolant and lubricant specification charts. STRUCTURE, FUNCTION AND MAINTENANCE STANDARD This section explains the structure and function of each component. It serves not only to give an understanding of the structure, but also serves as reference material for troubleshooting. TESTING, ADJUSTING AND TROUBLESHOOTING This section explains checks to be made before and after performing repairs, as well as adjustments to be made at completion of the checks and repairs. Troubleshooting charts correlating Problems to Causes are also mention in this section. DISASSEMBLY AND ASSEMBLY KOMATSU Excavator This section explains the order to be followed when removing, installing, disassembling or assembling each component, as well as precautions to be taken for these operations. POWER MAX. FUNCTION During digging operations, when that extra bit of digging power is needed (for example, when digging up boulders), the left knob switch can be pressed to raise the hydraulic pressure by approx. 10% and increase the digging force. If the left knob switch is pressed ON when the working mode is at H/O or G/O, each function is automatically set as follows. Working mode . . . . . . . . . . . . . . . . . . . . . . . Heavy duty operations Engine, pump controller . . . . . . . . . Matching at rated output point Cut off function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Canceled Actuating time . . . . . . . . . . . . . . . . . . . . Auto cancel after 8.5 sec.
