Komatsu PC400-7, PC400LC-7, PC450-7, PC450LC-7 Excavator Manual Workshop Guide

Manual Included: Shop Manual: 874 pages Specifications: Brand: Komatsu Model: PC400-7, PC400LC-7, PC450-7, PC450LC-7 Serial Number: PC400-7, PC400LC-7: 50001 and up PC450-7, PC450LC-7: 20001 and up Type: Excavator Manuals: Shop Manual Publication Number: SEBM037602 Language: English Format: PDF Description Table of Contents 01 GENERAL ……………………………………………………………… 01-1 10 STRUCTURE AND FUNCTION ……………………………….. 10-1 20 TESTING AND ADJUSTING…………………………………… 20-1 30 DISASSEMBLY AND ASSEMBLY …………………………… 30-1 90 OTHERS………………………………………………………………… 90-1 1. Composition of shop manual This shop manual contains the necessary technical information for services performed in a workshop. For ease of understanding, the manual is divided into the following sections. 00. FOREWORD This section explains the safety and basic information. 01. GENERAL This section explains the specifications of the machine for the Komatsu Excavator. 10. STRUCTURE AND FUNCTION, MAINTENANCE STANDARD This section explains the structure, function, and maintenance standard values of each component. The structure and function sub-section explains the structure and function of each component. It serves not only to give an understanding of the structure, but also serves as reference material for troubleshooting. The maintenance standard sub-section explains the criteria and remedies for disassembly and service. 20. TESTING AND ADJUSTING Standard value table This section explains the standard values for new machine and judgement criteria for testing, adjusting, and troubleshooting. This standard value table is used to check the standard values in testing and adjusting and to judge parts in troubleshooting. Testing and adjusting This section explains measuring instruments and measuring methods for testing and adjusting, and method of adjusting each part. The standard values and judgement criteria for testing and adjusting are explained in Testing and adjusting. Troubleshooting This section explains how to find out failed parts and how to repair them. The troubleshooting is divided by failure modes. The S mode of the troubleshooting related to the engine may be also explained in the Chassis volume and Engine volume. In this case, see the Chassis volume. 30. DISASSEMBLY AND ASSEMBLY Excavator This section explains the special tools and procedures for removing, installing, disassembling, and assembling each component, as well as precautions for them. In addition, tightening torque and quantity and weight of coating material, oil, grease, and coolant necessary for the work are also explain. 90. OTHERS (chassis volume)/Repair and replacement of parts (engine volume) • Chassis volume This section gives hydraulic circuit diagrams and electrical circuit diagrams. • Engine volume This section explains the method of reproducing, repairing, and replacing parts. Function • The engine revolution sensor is installed to the ring gear of the engine flywheel. It electrically calculates the number of the gear teeth which pass in front of it and transmits the result to the engine throttle and pump controller. • A magnet is used to sense the gear teeth. Each time a gear tooth passes in front of the magnet, a current is generated.
