Komatsu PC88MR-6 Excavator Service Manual Workshop Guide

Manual Included: Shop Manual: 328 pages Specifications: Brand: Komatsu Model: PC88MR-6 Type: Excavator Serial Number: F00003 and up Manuals: Shop Manual Publication Number: WEBM007200 Language: English Format: PDF Description Table of Contents 10. STRUCTURE AND FUNCTION……………………………………………………………………. 10-1 20. TESTING AND ADJUSTING ……………………………………………………………………….. 20-1 30. DISASSEMBLY AND ASSEMBLY ………………………………………………………………. 30-1 90. OTHER………………………………………………………………………………………………………. 90-1 GENERAL This section lists the general machine dimensions, performance specifications, component weights, and fuel, coolant and lubricant specification charts. STRUCTURE, FUNCTION AND MAINTENANCE STANDARD This section explains the structure and function of each component. It serves not only to give an understanding of the structure, but also serves as reference material for troubleshooting. TESTING, ADJUSTING AND TROUBLESHOOTING This section explains checks to be made before and after performing repairs, as well as adjustments to be made at completion of the checks and repairs. Troubleshooting charts correlating Problems to Causes are also mention in this section. DISASSEMBLY AND ASSEMBLY KOMATSU Excavator This section explains the order to be followed when removing, installing, disassembling or assembling each component, as well as precautions to be taken for these operations. ADJUSTING PC VALVE a If the engine speed drops when a pressure or load increase is demanded, or if the attachment speed is low when the engine speed, delivery pressure, and LS differential pressure is normal, then the PC valve (1) needs adjusting. To adjust PC valve, use the following procedure. a Before loosening nut (2), mark the positions (a) between the adjusting nut and screw (3). 1 -Loosen the nut (2) and adjust the pump torque absorption with screw (3). a The PC valve is an eccentric design valve, so the value of torque increase will never be known, whatever direction the screw is turned (3). On account of that, turn the screw (3) while at the same time checking the procedure on the engine speed monitor. 2 -Once the adjustment is completed, retain the position of the screw (3) and tighten the nut (2).
