Kubota G2160, G2160-R48S, G2460G Mower Workshop Service Manual

Kubota Mower Model G2160, G2160-R48S, G2460G Publication: 9Y011-15045 Format: PDF Language: English Kubota G2160, G2160-R48S, G2460G Mower Workshop Service Manual – 398 Pages Description Kubota G2160, G2160-R48S, G2460G Mower Workshop Service Manual Kubota Mower Model G2160, G2160-R48S, G2460G Publication: 9Y011-15045 Format: PDF Language: English Kubota G2160, G2160-R48S, G2460G Mower Workshop Service Manual – 398 Pages Table of Content of the Mower G2160, G2160-R48S, G2460G Workshop Service Manual This WORKSHOP MANUAL has been prepared to provide servicing personnel with information on the mechanism, service and maintenance of KUBOTA G2160, G2160-R48S, G2460G. It is divided into two parts, "MECHANISM" and "SERVICING" for each section except "ENGINE" section. ■ MECHANISM Information on the construction and function are included. This information should be understood before proceeding with troubleshooting, disassembling and servicing. ■ SERVICING OF THE G2160, G2160-R48S, G2460G MOWER The heading "GENERAL" includes general precautions, check and maintenance and special tools. Other section, there are troubleshooting, servicing specification lists, checking and adjusting, disassembling and assembling, and servicing which cover procedures, precautions, factory specifications and allowable limits STARTING FAILURE DIAGNOSIS Cautions in servicing • If two or more error codes are stored, perform failure diagnosis starting from the error code displayed first (whose flashing time is lowest). • When performing failure diagnosis based on the error code because the symptom complained of by the customer has no repeatability, obtain from the customer's detailed information about the conditions at the time of warning lamp going on and perform a test under the same conditions as much as possible. If the warning lamp does not go on in the test running, check for imperfect contact, etc. by shaking the harness or connector while following the failure diagnosis chart. • Do not connect or disconnect the connector with main switch turned ON. • The number indicating the coupler pin is shown viewed from the cord side for the female pen and male pin.
