Liebherr A910, A912, A914, A918, R914 Compact Tier 4i Excavator Service Manual

A 910 Compact 64722 and up ( Type 1186) A 912 Compact 65241 and up ( Type 1187) A 914 Compact 59926 and up ( Type 1188) A 918 Compact 53395 and up ( Type 1189) R 914 Compact 65677 and up ( Type 1194) Language: English Publication: 11182857 Format: PDF September 2017 Liebherr A910, A912, A914, A918, R914 Compact Tier 4i Excavator Service Manual – 2389 Pages Operator's manual – 328 Pages Description Liebherr A910, A912, A914, A918, R914 Compact Tier 4i Hydraulic Excavator Service Manual Excavator Appplicable Model : A 910 Compact 64722 and up ( Type 1186) A 912 Compact 65241 and up ( Type 1187) A 914 Compact 59926 and up ( Type 1188) A 918 Compact 53395 and up ( Type 1189) R 914 Compact 65677 and up ( Type 1194) Language: English Publication: 11182857 Format: PDF September 2017 Liebherr A910, A912, A914, A918, R914 Compact Tier 4i Excavator Service Manual – 2389 Pages Operator's manual – 328 Pages Table of Content of the Service Manual: Introduction Technical data Maintenance Drive group Cooling system Working hydraulics Hydraulic components Travel hydraulics Steering System Brake System Electrical system Travel gear mechanism Axles / Drive Steel parts – basic machine Working attachment Cab / heating / air conditioning Lubrication system Slewing gear mechanism / Slewing ring Software / Hardware Options This manual contains technical data, design and functional descriptions as well as instructions for the operation and the adjustment of machine settings. The document includes a number of drawings, functional schematics and detailed views of units and assemblies of Liebherr hydraulic excavators. All parts of a construction machine are exposed to corrosion, especially when the machine is taken out of service. Corrosion can be compared to wear. However, the effects of corrosion can greatly exceed that of mechanical wear and shorten the service life of the affected parts significantly. For that reason, for longer shut down, the machines and its components must be preserved according to certain guidelines. In general, these guidelines are tiered according to the following times: – Taking the machine out of service – for an unknown duration – Shut down of the machine • Shut down for up to 2 months • Shut down for up to 12 months • Shut down for longer than 12 months – Return to operation The required measures are graduated depending on the different time frames. The conservation measures cannot be strictly standardized and they must be shorted or lengthened depending on the assessment of necessity (such as environmental influences).
