Liebherr L506, L507, L508, L509, L510 Wheel Loader Service Manual

L 506 from serial 9099 (Type 776) L 507 from serial 9099 (Type 777) L 508 from serial 9099 (Type 778) L 509 from serial 9099 (Type 779) L 510 from serial 9099 (Type 782) Language: English Publication: 1011 2640 Format: PDF Liebherr L506, L507, L508, L509, L510 Wheel Loader Service Manual – 426 Pages Operating manual – 251 Pages Description Liebherr L506, L507, L508, L509, L510 Wheel Loader Manual Wheel Loader Applicable Model : L 506 from serial 9099 (Type 776) L 507 from serial 9099 (Type 777) L 508 from serial 9099 (Type 778) L 509 from serial 9099 (Type 779) L 510 from serial 9099 (Type 782) Language: English Publication: 1011 2640 Format: PDF Liebherr L506, L507, L508, L509, L510 Wheel Loader Service Manual – 426 Pages Operating manual – 251 Pages Table of Content of the Service Manual: General Special Tools Lubricants Technical Data- Inspection Plans Engine Travel Hydraulic Working Hydraulic Electrical System Heating, Air conditioning System Travel Gear Axles Steering Brakes Main Frame / Cab Hoist Frame / Accessories Special Installations This Service Manual has been written for those whose job it is to make sure that the machines remain operational on a daily basis. This specifically includes the mechanics and workshop specialists at Liebherr dealers and Liebherr branch offices. Contents In the first chapter you will find information about safety regulations as well as specifications of the special tools needed for maintenance and repair. Chapter 2 provides an overview of all important technical data for the entire machine and the individual assemblies. The following chapter, entitled Maintenance, contains the maintenance and inspection schedule, inspection and setting logs, lubrication schedules and filling quantity tables, a description of maintenance procedures and specifications for prescribed lubricants and fuels. The technical description of the machine in the following chapters is divided into 15 functional groups. The design, function, and technical data for each group, component and part are explained.
