Liebherr L544, L554 2plus2 Wheel Loader Service Manual

L544 from serial 6190 Type 443 L554 from serial 0501 Type 453 Language: English Publication: 10022903 Format: PDF Liebherr L544, L554 2plus2 Wheel Loader Service Manual – 718 Pages Operating manual – 298 Pages Description Liebherr L544, L554 2plus2 Wheel Loader Manual Wheel Loader Applicable Model : L544 from serial 6190 Type 443 L554 from serial 0501 Type 453 Language: English Publication: 10022903 Format: PDF Liebherr L544, L554 2plus2 Wheel Loader Service Manual – 718 Pages Operating manual – 298 Pages Table of Content of the Service Manual: General information Product description Maintenance Diesel engine, pump distributor gear Cooling System Travel Hydraulics Steering System Brake System Electrical System Transfer gear Axles and drive shafts Machine frame, ballast weight Central lubrication system Covering, cab access Cab, heating, air-conditioning Lift arm, quick-change device Attachments, accessories Repair work, troubleshooting In the first chapter you will find information about safety regulations as well as specifications of the special tools needed for maintenance and repair. Chapter 2 provides an overview of all important technical data for the entire machine and the individual assemblies. The following chapter, entitled Maintenance, contains the maintenance and inspection schedule, inspection and setting logs, lubrication schedules and filling quantity tables, a description of maintenance procedures and specifications for prescribed lubricants and fuels. The technical description of the L544, L554 2plus2 in the following chapters is divided into 15 functional groups. The design, function, and technical data for each group, component and part are explained. This manual describes a variety of types and finished forms. In general, this information applies to the types and serial number groups specified in the footnotes. One exception is that specific type and serial number data are indicated at the beginning of each section (e.g. the technical specifications of the components).
