Liebherr LH120M, LH120C Litronic Hydraulic Excavator Service Manual

LH 120 M from serial no 58854 (Type 1102) LH120 C Litronic from serial no 0095 (Type 1103) Language: English Publication: 11101175 Format: PDF December 2013 Liebherr LH120M, LH120C Litronic Excavator Service Manual – 1912 Pages Operator's manual – 302 Pages Description Liebherr LH120M, LH120C Litronic Excavator Manual Excavator Model : LH 120 M from serial no 58854 (Type 1102) LH120 C Litronic from serial no 0095 (Type 1103) Language: English Publication: 11101175 Format: PDF December 2013 Liebherr LH120M, LH120C Litronic Excavator Service Manual – 1912 Pages Operator's manual – 302 Pages Table of Content of the Service Manual: Introduction Technical data Maintenance Drive group Cooling system Working hydraulics Travel hydraulics Hydraulic components Steering system Brake system Electrical system Travel gear mechanism Axles / Drive Steel parts – basic machine Working equipment Cab / heating / air conditioning Lubrication system Slewing gear mechanism / Slewing ring Factory spezific Options This manual has been prepared to provide you with technical information on the design and construction of the various components which made up the LIEBHERR excavator. The main groups are listed in the main group directory. The subgroups are listed on the first page of each main group section. The subgroup list also includes the machines and serial numbers to which the subgroup is relevant. In the event of minor changes, we will send you the amended page showing the current date. If an existing subgroup is completely revised and re-edited, the new version will be assigned a new subgroup number. This service manual shall be amended without prior notice to reflect new technical developments and machine series The descriptions of work in this publication describe the necessary safety precau­tions which must be taken to prevent people and the machine from being exposed to hazards.
