Liebherr LH80M, LH80C Tier 4i Hydraulic Excavator Service Manual

LH 80 M from serial 49567 and up (Type 1205) LH 80 C from serial 62275 and up (Type 1213) Language: English Publication: 11651945 Format: PDF December 2015 Liebherr LH80M, LH80C Tier 4i Excavator Service Manual – 1477 Pages Operator's manual – 352 Pages Description Liebherr LH80M, LH80C Tier 4i Hydraulic Excavator Service Manual Excavator Model : LH 80 M from serial 49567 and up (Type 1205) LH 80 C from serial 62275 and up (Type 1213) Language: English Publication: 11651945 Format: PDF December 2015 Liebherr LH80M, LH80C Tier 4i Excavator Service Manual – 1477 Pages Operator's manual – 352 Pages Table of Content of the Service Manual: Introduction Technical data Maintenance Drive group Cooling system Working hydraulics Hydraulic components Steering System Brake System Electrical system Transmission /Travel gearbox Axles / Drive Steel components – basic machine Working attachment Operator's cab, heating and air conditioning Lubrication system Slewing gearbox and slewing ring Equipment / options Diagnosis This manual contains technical data, design and functional descriptions as well as instructions for the operation and the adjustment of machine settings. The document includes a number of drawings, functional schematics and detailed views of units and assemblies of Liebherr hydraulic excavators. Cleaning outside of machine Before cleaning Before cleaning with water or a high-pressure cleaner, perform following activities in order to avoid water penetration. Turn ignition button to position 0. Lubricate all bearings, pin connections and slewing ring, using central lubrication system, if available. Clean away oil, fuel or care products off connections and fittings. If sensitive parts behind openings have to be protected from penetrating water: u Cover or mask off openings. Parts particularly at risk are: – Electric motors – Electric components – Switch cabinets – Plug connections – Transmitters – Air filters Cleaning Use lint-free cleaning cloths. Do not clean machine with aggressive cleaning agents or flammable liquids. Soften up dirt with water. Rinse off softened dirt with water. If fire warning and extinguishing system is fitted: u Make sure that there is no possibility of the temperature sensors coming into contact with hot liquids during cleaning of the engine compartment. After cleaning Check all fuel lines, engine oil lines and hydraulic lines (leaks, loose connections, chafe marks and damage). Immediately rectify any defects that are detected.
