Linkbelt 1600Q Quantum Excavator Service Repair Manual Workshop Guide

Manual Included: Service Repair Manual: 464 pages Operators Manual: 154 pages Hydraulic and Electrical Schematics Specifications: Brand: LinkBelt Model: 1600Q (Quantum Series) Type: Excavator Manuals: Repair and Operators Manual Publication Numbers: 851 & 852 Language: English Format: PDF Description Table of Contents 1. Shop Manual Explanation Shop Manual Contents Safety Introduction Symbols Used Precautions Standard Torque Specifications Numerical Value Conversion Table 2. Specifications Major Equipment Specifications Lower Mechanism General View Lower Assembly Drawing Travel Equipment Idler Wheel Upper Roller Lower Roller Recoil Spring Shoe Upper Mechanism Swing Equipment Engine Engine Radiator Engine Control Fuel Tank Hydraulic Equipment Hydraulic Pump Hydraulic Reservoir Rotating Joint Controls Remote Control Valve Control Valve By-Pass Oil Filter Excavator Attachment Cylinder Filters, Fluids, and Lubricants 3. Performance Main Body Weight Suspension Performance 4. Main Body Disassembly and Servicing Procedures Lower Mechanism Travel Equipment Drive Sprocket Idler Wheel Upper Roller Lower Roller Recoil Spring Grease Cylinder Track Shoe Rotating Joint Attachment Bucket Cylinder Arm Cylinder Boom Cylinder Blade Cylinder Maintenance Standards 5. Major Components Disassembly and Service Procedures Tightening Torque for Major Parts Idler Wheel Upper Roller Lower Roller Recoil Spring Rotating Joint 6. Major Hydraulic Components Disassembly and Servicing Procedures Hydraulic Pump Pump Handling Pump Maintenance Travel Mechanism Operating Principle and Precautions for Use Disassembly and Maintenance Procedures Swing Mechanism Motor Assembly Motor Reduction Gear Control Valve Cylinder Multiple Solenoid Valve Stack Cushion Valve
