Linkbelt 6000Q SL, 6000Q RT SL Quantum Excavator Operators Manual Workshop Guide

Manual Included: Operators Manual: 84 pages (Tracked Scrape Loader) Operators Manual: 88 pages (Rubber-Tired Scrape Loader) Hydraulic and Electrical Schematics Specifications: Brand: LinkBelt Model: 6000Q (Quantum Series) Type: Scrape Loader Manuals: Operators Manual Publication Numbers: 834 & 901 Language: English Format: PDF Description Table of Contents 1. OPERATING SAFETY GENERAL SAFETY RULES OPERATOR AWARENESS MAGNET SAFETY INSTRUCTIONS ELECTRICAL DANGERS PROTECTIVE EQUIPMENT SIGNALMEN AND BYSTANDERS INSPECTIONS AND ADJUSTMENTS AREA CLEARANCE LEAVING THE STATION 2. OPERATOR'S CAB CONTROLS RIGHT CONTROL CONSOLE LEFT CONTROL CONSOLE 3. SYSTEMS CONTROL MONITOR 4. OPERATING SYSTEM CONTROLS ENGINE THROTTLE CONTROL JOYSTICK CONTROLLERS SWING OPERATION FREE SWING OPERATION TO SWING THE UPPER BOOM, ARM & JIB OPERATION (IF EQUIPPED) ATTACHMENT CONTROL OPERATION STEERING AND TRAVELING THE MACHINE 5. GENERAL OPERATION MAGNET OPERATION GRAPPLE OPERATION 6. HAND SIGNALS 7. CAB HEATER SHUTOFF VALVE 8. OPERATOR'S SEAT 9. ENTERING AND EXITING CAB 10. BREAK-IN PERIOD 11. BEFORE STARTING OPERATIONS 12. ENGINE STARTING PROCEDURE TO START THE ENGINE ETHER START TO START THE ENGINE USING ETHER START 13. ENGINE SHUTDOWN 14. FUSE PANEL 15. FRONT WINDOWS OPENING THE UPPER WINDOW CLOSING THE UPPER WINDOW REMOVING LOWER WINDOW INSTALLING LOWER WINDOW 16. TRANSPORTING THE MACHINE COUNTERWEIGHT REMOVAL/INSTALLATION REMOVAL PROCEDURES INSTALLATION PROCEDURES ATTACHMENT REMOVAL/INSTALLATION MACHINE LOADING AND UNLOADING LOADING THE MACHINE UNLOADING THE MACHINE TILTING/LIFTING OF ELEVATED CAB TILTING PROCEDURE LIFTING PROCEDURE 17. MACHINE STORAGE SHORT TERM STORAGE LONG TERM STORAGE ANTI-VANDAL GUARD INSTALLATION REMOVAL & STORAGE
