Manitou MHT 7140, MH T990, MHT 990 MHO Telehandler Repair Manual

Format: PDF Language: English Manitou Telehandler Applicable Model: MHT 7140 MH T990 MHT 990 MHO Manitou MHT 7140, MH T990, MHT 990 MHO Telehandler Repair Service Manual – 804 Pages Description Manitou MHT 7140, MH T990, MHT 990 MHO Telehandler Repair Manual Format: PDF Language: English Manitou Telehandler Applicable Model: MHT 7140 MH T990 MHT 990 MHO Manitou MHT 7140, MH T990, MHT 990 MHO Telehandler Repair Service Manual – 804 Pages Table of content of the Repair Manual: GENERAL INSTRUCTIONS AND SAFETY NOTICE INDEX CHARACTERISTICS ENGINE ENGINE TRANSMISSION HYDROSTATIC GEAR BOX-DROP BOX MO360A10 DIFFERENTIAL UNIT AXLE ASSEMBLY – AXLE AXLES PLANETARY DRIVE STEERING AXLE WITH WET DISC BRAKES AS 372 KR HYDRAULIC HYDRAULIC PUMP A11VO 75 DRS SERIES 10 PUMP A11VO 40 – 130 Series 10 ELECTRICITY ELECTRICAL OPTIONS – ACCESSORIES OPTIONAL This section contains general instructions and notes on safety for inspection and maintenance tasks. The efficiency and continued operation of mechanical units depend on constant, correct maintenance and also on efficient repair work, should there be a break-down or malfunction. The instructions contained in this MHT 7140, MH T990, MHT 990 MHO Telehandler repair manual have been based on a complete overhaul of the unit. However, it is up to the mechanic to decide whether or not it is necessary to assemble only individual components, when partial repair work is needed. The manual provides a quick and sure guide which, with the use of photographs and diagrams illustrating the various phases of the operations, allows accurate work to be performed.All the information needed for correct disassembly, checks and assembly of each individual component is set out below. In order to remove the differential unit from the vehicle, the manuals provided by the vehicle manufacturer should be consulted. In describing the following operations it is presumed that the unit has already been removed from the vehicle. INTRODUCTORY REMARKS: All the disassembled mechanical of  the MHT 7140, MH T990, MHT 990 MHO should be thoroughly cleaned with appropriate products and restored or replaced if damage, wear, cracking or seizing have occurred. In particular, thoroughly check the condition of all moving parts (bearings, gears, crown wheel and pinion, shafts) and sealing parts (o-rings, oil shields) which are subject to major stress and wear. In any case, it is advisable to replace the seals every time a component is overhauled or repaired. During assembly, the sealing rings must be lubricated on the sealing edge. In the case of the crown wheel and pinion, replacement of one component requires the replacement of the other one. During assembly, the prescribed pre-loading, backlash and torque of parts must be maintained.
