Massey Ferguson 2604H, 2605H, 2606H, 2607H Tractor Service Manual Workshop Guide

Massey Ferguson 2604H, 2605H, 2606H, 2607H Tractors Workshop Manual – 597 Pages Parts Catalog – 92 Pages Format: PDF Language: English Publication No: 4283604M1 Description Massey Ferguson 2604H, 2605H, 2606H, 2607H Tractor Manual Model: Massey Ferguson Tractor Format: PDF Language: English Publication No: 4283604M1 Massey Ferguson 2604H, 2605H, 2606H, 2607H Tractors Workshop Manual – 597 Pages Parts Catalog – 92 Pages Manual Table of Content INTRODUCTION AND SAFETY……………………………………………………………………………………………………………..01 MISCELLANEOUS DATA …………………………………………………………………………………………………………………….02 TRACTOR IDENTIFICATION AND SPECIFICATIONS …………………………………………………………………………….03 SPLITTING THE TRACTOR ………………………………………………………………………………………………………………….04 SHEET METAL…………………………………………………………………………………………………………………………………….05 ENGINE – SJV326-26 FEB 2016 ……………………………………………………………………………………………………………06 FRONT AXLE 2WD ……………………………………………………………………………………………………………………………07A G4 FRONT AXLE WSM ………………………………………………………………………………………………………………………07B DUAL CLUTCH ………………………………………………………………………………………………………………………………….08A SPLIT TORQUE CLUTCH …………………………………………………………………………………………………………………..08B 8X2 TRANSMISSION………………………………………………………………………………………………………………………….09A 8X8 TRANSMISSION………………………………………………………………………………………………………………………….09B TRANSFER GEAR BOX……………………………………………………………………………………………………………………..09C REAR AXLE AND OIL IMMERSED BRAKE………………………………………………………………………………………….10A REAR AXLE DRUM BRAKE-DIRECT DRIVE………………………………………………………………………………………..10B HYDRAULICS ……………………………………………………………………………………………………………………………………11A AUXILIARY HYDRAULICS ………………………………………………………………………………………………………………….11B STEERING SYSTEM …………………………………………………………………………………………………………………………..11C LIVE PTO ………………………………………………………………………………………………………………………………………….12A INDEPENDENT PTO…………………………………………………………………………………………………………………………..12B CGENERAL ELECTRICALS………………………………………………………………………………………………………………..13A STARTER MOTOR……………………………………………………………………………………………………………………………..13B ALTERNATOR…………………………………………………………………………………………………………………………………..13C The purpose of this manual is to assist Dealers and Distributors in the efficient repair and maintenance of MF2600 H Series farm tractors. Carrying out the procedures as detailed, together with the use of special tools where appropriate, will enable the operations to be completed within the time stated in the Repair Time Schedule (Parts Catalog). To assist with locating information, each section of the manual is preceded by a contents page listing the operations. Each instruction within an operation has a sequence number, and to complete the operation in the minimum time it is essential that these instructions are performed in numerical sequence commencing at 1, unless otherwise stated. When applicable, these sequence numbers identify the components in the appropriate illustration. When an operation requires the use of a special tool, the tool number is quoted under the operation heading and is repeated in, or following, the instruction involving its use.
