Massey Ferguson 4215, 4220, 4243, 4253, 4263 Tractor Service Manual

Massey Ferguson 4215, 4220, 4243, 4253, 4263 Tractors Workshop Manual – 752 Pages Format PDF English Description Massey Ferguson 4215, 4220, 4243, 4253, 4263 Tractor Manual Model: Tractor 4215, 4220, 4243, 4253, 4263 Format PDF English Massey Ferguson 4215, 4220, 4243, 4253, 4263 Tractors Workshop Manual – 752 Pages Manual Table of Content Introduction Splitting the Tractor Engine Clutch Gearbox Rear Axle PTO Front Axle Hydraulics and Steering Electrical Electronics Cab and Equipment Accessories Service Tools Manual Extract ADJUST AND BALANCE BRAKES- Procedure 1. Ensure that all the air is removed from the hydraulic brake system. 2. Check the brake fluid level in the reservoir, top-up if necessary. 3. Place the tractor on level ground. Initial Foot Brake Setting 4. With the rear wheels attached, jack up the rear of the tractor and place it on axle stands with the wheels clear of the ground. 5. Slacken off the parking brake cable on the right-hand side of the tractor. 6. With the aid of an assistant, rotate one of the wheels slowly, at the same time tighten the adjuster nut until the wheel just locks. It is important to always rotate the wheel forwards. 7. The brake expander clearance is adjusted by unscrewing the adjuster nut a number of flats backoff related to the number of friction plates fitted to one side of the axle, see table below: 8. Carry out the same operation on the left-hand side of the tractor.
