Massey Ferguson 4607M, 4609M, 4610M, 4610M HC Tractor Service Manual Workshop Guide

Massey Ferguson 4607M, 4609M, 4610M, 4610M HC Tractors Workshop Manual – 598 Pages Parts Catalog – 141 Pages Format: PDF Language: English Publication No: 4283598M2 Description Massey Ferguson 4607M, 4609M, 4610M, 4610M HC Tractor Manual Model: Massey Ferguson Tractor Format: PDF Language: English Publication No: 4283598M2 Massey Ferguson 4607M, 4609M, 4610M, 4610M HC Tractors Workshop Manual – 598 Pages Parts Catalog – 141 Pages Manual Table of Content 1. Introduction 2. General 3. Engine Fuel Exhaust 4. Drive Train System 5. Chassis 6. Cab 7. Axles 8. Brake System 9. Electrical System 10. Hydraulic System 11. Steering System The service manual Read the table of contents and basic layout. Become familiar with all parts of this service manual. This service manual gives the technician very important information. Machine movement when in normal use determines right-hand and left-hand. This manual covers general safety practices for this machine. Air conditioner In the air conditioner system, the compressor speed changes and the required volume of the refrigerant also changes as the engine speed changes. The receiver tank stores refrigerant to use when increase volume is required. When the cooling circuit does not require as much refrigerant, the tank stores the extra refrigerant. When the system requires more refrigerant, the reciever tube supplies the necessary volume to the circuit. The tanks holds extra refrigerant to supply the circuit when refrigerant is lost through the hoses because of osmosis. Dryer (desiccant) Moisture content in the cooling circuit will cause valve damage in the compressor. Moisture will also cause decrease lubricant performance, pitting of the metal surfaces in the circuit, and stopped-up circuit caused by freezing in the expansion valve. In the air conditioner system a synthetic zeolite is used as an approved desiccant to remove moisture content from the circuit. A frozen expansion valve shows that the desiccant has lost function to take in moisture content, so the receiver dryer must be replaced. IMPORTANT: When the cooling circuit is disassembled and left out for a long time, the desiccant will take in moisture that is in the air. This will decrease the desiccant life. This will cause the replacing the receiver dryer. When the cooling circuit is disassembled, make sure to close up the opening without fail.
