Massey Ferguson 6712S, 6713S, 6714S Tractor Service Manual Workshop Guide

Massey Ferguson 6712S, 6713S, 6714S Tractors Workshop Manual – 1378 Pages Technician Service Book – MF 6700 S – 758 Pages AGCO Power 5th Generation AWF Engines – 198 Pages Spicer Axle 735 and 740 Service Manual – 176 Pages Parts Catalog Dyna – 496 Pages & 438 Pages Format: PDF Language: English Publication No: ACT0025630 Description Massey Ferguson 6712S, 6713S, 6714S Tractor Manual Model: Massey Ferguson MF 6700 Series Tractor Format: PDF Language: English Publication No: ACT0025630 Massey Ferguson 6712S, 6713S, 6714S Tractors Workshop Manual – 1378 Pages Technician Service Book – MF 6700 S – 758 Pages AGCO Power 5th Generation AWF Engines – 198 Pages Spicer Axle 735 and 740 Service Manual – 176 Pages Parts Catalog Dyna – 496 Pages & 438 Pages Manual Table of Content 1 Introduction 2 Separation of assemblies 3 Engine 4. Clutch 5. Gearbox 6. Rear axle 7. Power Take Off 8. Front axle 9. Hydraulics 10. Electricity 11. Electronics 12 Operator environment 13 Accessories 14 Service Tools Removing/refitting the pump Procedure 1. Remove and refit the cover plate (see chapter Removing/refitting the cover plate, page 9-149 ). 2. Remove the screws (2) and release and remove the pump (32). Remove the "O" rings (22) (23). NOTE: The centring pins (21) are force-fitted into the cover. Refitting Procedure 1. Clean the components and replace any defective parts. Check that none of the related cover plate channels are obstructed. 2. Fit the centring pins (21) to the cover plate (if required). 3. On the cover plate, fit new "O" rings (22) (23) in the recesses of the high and low flow rate channels. 4. Inside the cover plate, apply a bead C of Loctite 574 or equivalent around the four pump screw holes. 5. Refit the pump on the centring pins. 6. Smear the screws (2) with Loctite 221 or equivalent, and tighten them to a torque of 10 Nm–12 Nm. 7. Reassemble and refit the cover plate (see chapter Removing/refitting the cover plate, page 9-149 ).
