Massey Ferguson FC33 Front Mower Service Manual Workshop Guide

Massey Ferguson FC33 Mower Workshop Manual – 214 Pages Model: Mower FC33 Format: PDF Language: English Type: Workshop Service Manual Publication No: 4283356M1 Description Massey Ferguson FC33 Front Mower Manual Model: Mower FC33 Format: PDF Language: English Type: Workshop Service Manual Publication No: 4283356M1 Massey Ferguson FC33 Mower Workshop Manual – 214 Pages Manual Table of Content INTRODUCTION……………………………………………………………………………………………………………………………………………..01 DISASSEMBLY OF MAJOR COMPONENTS…………………………………………………………………………………………………….02 ENGINE ACCESSORIES…………………………………………………………………………………………………………………………………03 CLUTCH …………………………………………………………………………………………………………………………………………………………04 TRANSMISSION………………………………………………………………………………………………………………………………………………05 FRONT AXLE AND BRAKES……………………………………………………………………………………………………………………………06 REAR AXLE…………………………………………………………………………………………………………………………………………………….07 STEERING SYSTEM……………………………………………………………………………………………………………………………………….08 HYDRAULIC SYSTEM……………………………………………………………………………………………………………………………………..09 ELECTRICAL SYSTEM……………………………………………………………………………………………………………………………………10 ASSEMBLY …………………………………………………………………………………………………………………………………………………….11 MOWER DECK ……………………………………………………………………………………………………………………………………………….12 INDEX …………………………………………………………………………………………………………………………………………………………….13 CLUTCH ASSEMBLY Disassembly Separate the clutch housing from the engine. Remove the clutch assembly from the flywheel. NOTE: When loosening tight bolts, loosen gradually in diagonal order. keep the oil off the clutch disc facings. Two reamer bolts are used to determine the installed position of the clutch housing. Inspection Inspection of clutch disc Check the clutch disc for wear or cracks on the facing, loose rivets, broken torsion springs, or wear of the hub splines. Measure the suppression of the rivets. If the suppression is 0.2 mm (0.0078 in)or less and cracks or burnt damage are found on the surface, the disc must be replaced. (1) Rivet Suppression (2) Clutch Disc NOTE: Make sure to replace any clutch disc which has 0.2 mm (0.0078 in) or less in rivet depression. Use of a disc with insufficient rivet depression will result in serious damage to the flywheel and the pressure plate. Any oil stained clutch disc must be replaced. However, a very small oil stain must be removed by use of a volatile solvent.
