Mitsubishi 2FBC25, 2FBC25E, 2FBC30 Forklift Service Manual

Mitsubishi 2FBC25, 2FBC25E, 2FBC30 Forklift  Service Manual: 293 Pages Publication 99759-70100 English Format: PDF Description Mitsubishi 2FBC25, 2FBC25E, 2FBC30 Lift Truck Manual Lift Truck Forklift Model : 2FBC25, 2FBC25E, 2FBC30 Publication 99759-70100 English Format: PDF Mitsubishi 2FBC25, 2FBC25E, 2FBC30 Forklift  Service Manual: 293 Pages Forklift Manual Table of Content: General Information Front Axle & Reduction Differential Transfer Case Rear Axle Brake System Steering System Hydraulic System Mast and Forks Troubleshooting Section Maintenance Service Data This service manual deals with all components or systems of the Mitsubishi Forklift Trucks, except for the electrical system, which is covered in a Controller manual Brake System This device adjusts the drum-to-lining clearance automatically. As the clearance increases due to lining wear, the lever mechanism of this device turns the adjusting screw by one notch or tooth to reposition the shoes closer to the drum. This corresponds to 1/24 of one rotation or 15° . In the course of usage, the adjusting process repeats itself at long intervals.
