Mitsubishi FB20CA, FB20HCA, FB25CA, FB25HCA Forklift Service Manual

Mitsubishi FB20CA, FB20HCA, FB25CA, FB25HCA Forklift  Service Manual: 247 Pages Controller Manual: 201 Pages English Format: PDF Description Mitsubishi FB20CA, FB20HCA, FB25CA, FB25HCA Lift Truck Manual Lift Truck Forklift Model : FB20CA, FB20HCA, FB25CA, FB25HCA English Format: PDF Mitsubishi FB20CA, FB20HCA, FB25CA, FB25HCA Forklift  Service Manual: 247 Pages Controller Manual: 201 Pages Forklift Manual Table of Content: General Information Front Axle Rear Axle Tyre Steering Brake Hydraulic System Pump Oil Tank and Oil Piping Cylinder Mast Motor Electrical System Service Data This service manual deals with all components or systems of the Mitsubishi Forklift Trucks, except for the electrical system, which is covered in a Controller manual Tilt cylinder – installation 1. Install the tilt cylinder in reverse order of removal. 2. Operate the tilt lever and make sure if the mast is not twisted at both forward and backward ends. If the mast is twisted, adjust the length of the rod by turning the head. After adjustment, tighten the nut on the head. 3. Make sure that oil is not leaked from anywhere around the tilt cylinder The tilt cylinder may be required to modify or replace if the mast is exchanged for another one with different lifting height. Refer the section 7d-3 for details.
