New Holland C175 Track Loader Service Manual Workshop Guide

Manual Included: Workshop Manual: 967 pages Specifications: Brand: New Holland Model: C175 Type: Track Loader Manuals: Workshop Manual Publication Numbers: 87690289 Language: English Format: PDF Description Table of Content (Workshop Manual) SPECIFICATIONS MODEL ………………………………………………………………………………………………………………………….. C175 ENGINE MANUFACTURER………………………………………………………………………………………………. NEW HOLLAND MODEL……………………………………………………………………………………………………………………………… N844LT Diesel CYLINDERS…………………………………………………………………………………………………………………………………………..4 ASPIRATION……………………………………………………………………………………………………………………………….. TURBO CYCLE…………………………………………………………………………………………………………………………………….4 STROKE BORE AND STROKE………………………………………………………………………………… 84 X 100 mm (3.30 in. X 3.91 in.) DISPLACEMENT……………………………………………………………………………………………….. 2212 cu. cm (135.0 cu. in.) COMPRESSION RATIO…………………………………………………………………………………………………………………..22 to 1 SPEEDS High Idle (No Load)- North American Machines…………………………………………………………………..3050 25 RPM High Idle (No Load)- European Machines…………………………………………………………………………..2750 25 RPM Low Idle (No Load)- North American Machines …………………………………………………………………..1200 50 RPM Low Idle (No Load)- European Machines……………………………………………………………………………1200 50 RPM HORSEPOWER (SAE Gross) – North American Machines …………………………………………………………………….60 HP at 2900 RPM (SAE Gross) – European Machines…………………………………………………………………57 HP (43 KW) at 2600 RPM (SAE Net) – North American Machines…………………………………………………………………………56 HP at 2900 RPM (SAE Net) – European Machines…………………………………………………………………….55 HP (41 KW) at 2600 RPM The Manual Preface This Manual has been written for the repair specialist. It provides important information on carrying out repair work expertly. Please go carefully through the Workshop Manual of the Track Loader before starting any repair work. Use the Workshop Manual of the C175 Loader as a reference book and source of information even if you are familiar with Track Loader technology. Using this the experience construction machine mechanic can carry out any necessary repairs expertly. Sections of the Manual The Manual is into main groups and subgroups, and covers any previous version of the machine. Any additions or modifications which can happen at a later date are not describe in this manual. The required information can easily be found by referring to the table of contents. For reasons of clarity, some of the illustrations are presented in simplified form. Differences from the actual version of this manual are therefore possible if this adds to the clarity of the information. Repair and Parts Carry out any necessary repair work as soon as possible. This reduces repair costs and increases the availability of your Track Loader When doing any work on the Track Loader, always observe the instructions given in the Workshop Manual. Extensive works not described in this Workshop Manual will gladly be executed for you by your dealer. Always use original spare parts only.
