New Holland EC15, EC25, EC35, EC45 Mini Excavator Service Manual Workshop Guide

Manual Included: • Service Manual: 415 pages Specifications: • Brand: New Holland • Model: EC15, EC25, EC35 and EC45 • Type: Crawler Mini Excavator • Manuals: Service Manual • Publication Numbers: 8661172601R0 • Language: English • Format: PDF Description Table of content (Service Manual) SECTION 00 – GENERAL INFORMATION SECTION 6 – ELECTRICAL SYSTEM SECTION 7 – HYDRAULIC SYSTEM SECTION 10 – OPERATORS PLATFORM SECTION 11 – TRACTION/UNDERCARRIAGE Instructions This manual covers the repair and adjustment procedures for the New Holland Model EC15, EC25, EC35, EC45 Mini Excavator. All repair and maintenance work listed in this manual must be carried out only by qualified personnel, strictly complying with the instructions given, and using, whenever possible, the special tools. Thoroughly read and understand this Service manual and the Operators Manual before operating any repair or servicing. For easy references the manual is breakdown in several chapter with an easy to follow instruction for repairing guidance of the different part of the Excavator. MODEL ENGINE TYPE – HORSEPOWER EC15 Mitsubishi L3E four-stroke diesel engine – 17.8 hp EC25 Mitsubishi S4L- 61KL four-stroke diesel engine – 27.5 hp EC35 Mitsubishi S4L-2-61KL four-stroke diesel engine – 35.5 hp EC45 Mitsubishi S4Q2-61KL four-stroke diesel engine – 46.4 hp
