New Holland L140 and L150 SkidSteer Service Manual Workshop Guide

Manual Included: • Repair Manual: 686 pages Specifications: • Brand: New Holland • Model: L140 and L150 • Type: SkidSteer • Manuals: Repair Manual • Publication Numbers: 87634743 • Language: English • Format: PDF Description TABLE OF CONTENTS ( Repair Manual) 00 – GENERAL INFORMATION 10 – ENGINE 29 – HYDROSTATIC TRANSMISSION 33 – BRAKES AND CONTROLS 35 – HYDRAULIC SYSTEM 37 – TOWING HOOKS AND BALLASTING 39 – FRAMES 44 – AXLES AND WHEELS 50 – CAB CLIMATE CONTROL 55 – ELECTRICAL SYSTEM 82 – FRONT LOADER (BOOM AND MOUNTING PLATE) 88 – ACCESSORIES 90 – PLATFORMS, CAB, BODYWORK, AND DECALS The Manual Preface The Workshop Manual has been written for the repair specialist. It provides important information on carrying out repair work expertly. Please go carefully through the Workshop Manual before starting any repair work. Use the Workshop Manual as a reference book and source of information even if you are familiar with SkidSteer Loader technology. Using the Workshop Manual, the experience construction machine mechanic can carry out any necessary repairs expertly. Sections of the Manual The Manual is into main groups and subgroups, and covers any previous version of the machine. Any additions or modifications which can happen at a later date are not describe in this manual. The require d information can easily be found by referring to the table of contents. For reasons of clarity, some of the illustrations are present in simplified form. Differences from the actual version are therefore possible if this adds to the clarity of the information. REPAIR and Parts Carry out any necessary repair work as soon as possible. This reduces repair costs and increases the availability of your SkidSteer Loader When doing any work on the loader, always observe the instructions given in the Workshop Manual. Extensive works not described in the New Holland Workshop Manual will gladly be executed for you by your dealer. Always use original spare parts only.
