New Holland L221, L228, C227, C232, C237 Tier 4B SkidSteer Loader Manual Workshop Guide

Manual Included: • Service Manual: 2117 pages and 2473 pages Specifications: • Brand: New Holland • Model: L221 Tier 4B (final), L228 Tier 4B (final), C227 Tier 4B (final), C232 Tier 4B (final) and C237 Tier 4B • Serial Number: L221 Tier 4B (final) (PIN: NEM479941 and above) L228 Tier 4B (final) (PIN: NFM401546 and above) C227 Tier 4B (final) (PIN: NDM471836 and above) C232 Tier 4B (final) (PIN: NFM402195 and above) • Type: SkidSteer • Manuals: Service Manual • Publication Numbers: 47851950 (May 2015) • Language: English • Format: PDF Description TABLE OF CONTENTS INTRODUCTION ENGINE POWER COUPLING FRONT AXLE SYSTEM REAR AXLE SYSTEM HYDROSTATIC DRIVE BRAKES AND CONTROLS HYDRAULIC SYSTEMS FRAMES AND BALLASING WHEELS CAB CLIMATE CONTROL ELECTRICAL SYSTEM FRONT LOADER AND BUCKET PLATFORMS, CAB, BODYWORK, AND DECALS The Manual Preface The Workshop Manual has been written for the repair specialist. It provides important information on carrying out repair work expertly. Please go carefully through the Workshop Manual of the SkidSteer Loader before starting any repair work. Use the Workshop Manual of the as a reference book and source of information even if you are familiar with SkidSteer Loader technology. Using the Workshop Manual, the experience construction machine mechanic can carry out any necessary repairs expertly. Sections of the Manual The Manual is into main groups and subgroups, and covers any previous version of the machine. Any additions or modifications which can happen at a later date are not describe in this manual. The require d information can easily be found by referring to the table of contents. For reasons of clarity, some of the illustrations are present in simplified form. Differences from the actual version are therefore possible if this adds to the clarity of the information. Repair and Parts Carry out any necessary repair work as soon as possible. This reduces repair costs and increases the availability of your SkidSteer Loader When doing any work on the loader, always observe the instructions given in the Workshop Manual. Extensive works not described in the New Holland Workshop Manual will gladly be executed for you by your dealer. Always use original spare parts only. Identify the Tier Level of your Equipment (Read our Article on Tier Level )
