New Holland U80C Tractor Backhoe Service Manual Workshop Guide

Manual Included: • Service Manual: 1926 pages (Tier 4B Final), 135 pages (Tier 4) Specifications: • Brand: New Holland • Model: U80C Tier 4 and U80C Tier 4B (final) • Type: Backhoe Loader • Manuals: Service Manual • Publication Numbers: 47441616 (Sep 2012) and 47821918 (April 2015) • Language: English • Format: PDF Description Table of Content (Service Manual) Contents Introduction Engine Transmission Front Axle Rear Axle Brake and Controls Hydraulic Systems Hitches, drawbars and coupling Frames and ballasting Steering Wheels Cab climate control Electrical systems Front loader and bucket Platform, cab, bodywork and decals Special Tool Index Electrical Schematics Hydraulic Schematics The Manual Preface The U80C Backhoe Loader Workshop Manual has been written for the repair specialist. It provides important information on carrying out repair work expertly. Please go carefully through the Workshop Manual of the backhoe loader before starting any repair work. Use the Workshop Manual as a reference book and source of information even if you are familiar with backhoe loader technology. Using the Workshop Manual, the experience construction machine mechanic can carry out any necessary repairs expertly. Sections of the Manual The Manual is into main groups and subgroups, and covers any previous version of the machine. Any additions or modifications which can happen at a later date are not describe in this manual. The required information can easily be found by referring to the table of contents. For reasons of clarity, some of the illustrations are presented in simplified form. Differences from the actual version at are therefore possible if this adds to the clarity of the information. Repair and Parts Carry out any necessary repair work as soon as possible. This reduces repair costs and increases the availability of your backhoe loader When doing any work on the backhoe loader, always observe the instructions given in the Workshop Manual. Extensive works not described in Workshop Manual will gladly be executed for you by your dealer. Always use original spare parts only.
