Takeuchi TB015 Compact Excavator Service Manual Workshop Guide

Takeuchi TB015 Service Repair Manual – 328 Pages Takeuchi TB015 Operating Manual – 100 Pages Parts Manual for TB015 – 255 Pages Description Takeuchi TB015 Compact Excavator Service Manual Type: Excavator TB015 Format: PDF Language of the Manual: English Excavator Serial Number : 1153001 -1158122 Takeuchi TB015 Service Manual – 328 Pages Takeuchi TB015 Operating Manual – 100 Pages Parts Manual for TB015 – 255 Pages The manual describes operation, service, repair and maintenance of the excavator, as well as safety instructions that should be follow. The Takeuchi TB015 manual is intended for persons who engage in maintenance operations, and explains procedures for disassembly and reassembly of the machine, check and maintenance procedures, maintenance reference values, troubleshooting and outline specifications, etc. Please use this Takeuchi manual for excavator TB015 as a reference in service activities to improve maintenance techniques. Please note that the contents and diagrams included in this manual may not match your machine exactly. Items or diagram which manual contains are subject to change without notice due to design modifications, etc. Always store the Takeuchi excavator manual near at hand preferably on the machine itself. When transferring ownership of this machine, be sure to provide the owner manual to the next owner. Table of Content of TB015 Instructions Manual: I . GENERAL II . SPECIFICATIONS III. MACHINE CONFIGURATION IV. HYDRAULIC UNITS V . TROUBLESHOOTING VI. ENGINE Before operating, perform the prescribe inspections and make repairs immediately should any irregularities be found. If a failure that causes loss of control such as steering, service brakes or engine occurs, stop the machine motion as quickly as possible, follow the shutdown procedure, and keep machine securely park until the problem is fixed. Extract from the Service Manual: Removing the Boom • Lower the front end of the boom so that it is in full contact with the ground. 1. Disconnect the hydraulic hoses (1) from the arm cylinder (2). 2. Suspend the arm cylinder (2) temporarily, then take out the pin (3) and remove the arm cylinder. • Arm Cylinder Weight : Approx. 12 kg 3. Suspend the boom cylinder temporarily and take out the pin (4). • The disconnected end of the cylinder rod should be resting on. the ground. 4. Disconnect the wiring to the boom light. 5. Disconnect the hydraulic hoses (6) from the pipes (7) 6. Suspend the boom (8) temporarily, take out the pin (9) and remove the boom. • Boom Weight: Approx. 49 kg Installing the Boom Follow the procedure used for removal in reverse order.
