Takeuchi TB1140 Compact Excavator Service Manual Workshop Guide

Takeuchi TB1140 Service Repair Manual – 460 Pages Takeuchi TB1140 Operating Manual – 229 Pages Parts Manual for TB1140 – 437 Pages ISUZU Engine Manual BB-4BG1-TRE – 81 Pages Description Takeuchi TB1140 Compact Excavator Service Manual Type: Excavator TB1140 Format: PDF Language of the Manual: English and French Takeuchi TB1140 Service Manual – 460 Pages Takeuchi TB1140 Operating Manual – 229 Pages Parts Manual for TB1140 – 437 Pages ISUZU Engine Manual BB-4BG1-TRE – 81 Pages For All applicable S/N Two different Version of the Service Manual – English and French The manual describes operation, service, repair and maintenance of the excavator, as well as safety instructions that should be follow. The Takeuchi TB1140 manual is intended for persons who engage in maintenance operations, and explains procedures for disassembly and reassembly of the machine, check and maintenance procedures, maintenance reference values, troubleshooting and outline specifications, etc. Please use this Takeuchi manual for excavator TB1140 as a reference in service activities to improve maintenance techniques. Please note that the contents and diagrams included in this manual may not match your machine exactly. Items or diagram which manual contains are subject to change without notice due to design modifications, etc. Always store the Takeuchi excavator manual near at hand preferably on the machine itself. When transferring ownership of this machine, be sure to provide the owner manual to the next owner. Table of Content of TB1140 Instructions Manual: I . GENERAL II . SPECIFICATIONS III. MACHINE CONFIGURATION IV. HYDRAULIC UNITS V . TROUBLESHOOTING VI. ENGINE Before operating, perform the prescribe inspections and make repairs immediately should any irregularities be found. If a failure that causes loss of control such as steering, service brakes or engine occurs, stop the machine motion as quickly as possible, follow the shutdown procedure, and keep machine securely park until the problem is fixed. Extract from the Service Manual: Carry out disassembly and assembly operations in a clean place and provide clean containers to place the disassembled parts in. • Before disassembly, clean around the ports and remove the paint from each joint using a wire brush. • Clean each of the disassembled parts with a cleaning oil such as diesel fuel. • Make match marks on each part so that they will be assembled in the same positions when assembled. • Replace all seals with new ones each time the pump is disassembled, coating them lightly with grease. • Check each part to make sure there is no abnormal wear or seizing and use sandpaper, etc. to remove any burrs, sharp edges, etc. • Adjust adjustment screws only when required.
