Takeuchi TB228 Compact Excavator Service Manual Workshop Guide

Language of the Manual: English Takeuchi TB228 Service Repair Manual – 293 Pages Takeuchi TB228 Operating Manual – 253 Pages Parts Manual for TB228 – 482 Pages Description Takeuchi TB228 Compact Excavator Service Manual Type: Excavator TB228 Format: PDF Language of the Manual: English Takeuchi TB228 Service Manual – 293 Pages Takeuchi TB228 Operating Manual – 253 Pages Parts Manual for TB228 – 482 Pages For All applicable S/N The manual describes operation, service, repair and maintenance of the excavator, as well as safety instructions that should be follow. The Takeuchi TB228 manual is intended for persons who engage in maintenance operations, and explains procedures for disassembly and reassembly of the machine, check and maintenance procedures, maintenance reference values, troubleshooting and outline specifications, etc. Please use this Takeuchi manual for excavator TB228 as a reference in service activities to improve maintenance techniques. Please note that the contents and diagrams included in this manual may not match your machine exactly. Items or diagram which manual contains are subject to change without notice due to design modifications, etc. Always store the Takeuchi excavator manual near at hand preferably on the machine itself. When transferring ownership of this machine, be sure to provide the owner manual to the next owner. Table of Content of TB228 Instructions Manual: I . GENERAL II . SPECIFICATIONS III. MACHINE CONFIGURATION IV. HYDRAULIC UNITS V . TROUBLESHOOTING VI. ENGINE Before operating, perform the prescribe inspections and make repairs immediately should any irregularities be found. If a failure that causes loss of control such as steering, service brakes or engine occurs, stop the machine motion as quickly as possible, follow the shutdown procedure, and keep machine securely park until the problem is fixed. Extract from the Manual: Every 250 hours – Replacing the engine oil and the oil filter – Inspecting and adjusting the fan belt – Inspecting and adjusting the compressor belt (AC) – Cleaning the air cleaner – Cleaning the radiator fins and oil cooler fins – Cleaning the air filters – Cleaning the condenser (AC) – Inspecting the refrigerant (gas) level (AC) Every 500 hours – Replacing the fuel filter 5-39 Every 1000 hours – Replacing the hydraulic oil return filter – Replacing the pilot line filter – Replacing the travel motor gear oil – Cleaning the engine cooling system – Replacing the air cleaner element – Replacing the air breather filter (If equipped) – Inspecting and adjusting the engine valve clearance – Retightening the engine cylinder head bolt Every 1500 hours – Inspecting and cleaning the engine fuel injectors – Inspecting the crankcase breather system Every 2000 hours – Lapping the engine valve seats Every 4000 hours – Replacing the hydraulic oil and cleaning the suction strainer
