Takeuchi TL240 Loader Service Manual Workshop Guide

Language of the Service and Operating Manual: English & French Takeuchi TL240 Service Repair Manual – 343 Pages Takeuchi TL240 Operators Manual – 212 Pages Parts Manual – 402 Pages Engine Manual for TL240 4TNV98T-ZNTBL -46 Pages Description Takeuchi TL240 Compact Loader Service Manual Type: Loader TL240 Format: PDF Language of the Service and Operating Manual: English & French Takeuchi TL240 Service Manual – 343 Pages Takeuchi TL240 Operators Manual – 212 Pages Parts Manual – 402 Pages Engine Manual for TL240 4TNV98T-ZNTBL -46 Pages For All applicable S/N The manual describes operation, service, repair and maintenance of the Loader, as well as safety instructions that should be follow. The Takeuchi TL240 manual is intended for persons who engage in maintenance operations, and explains procedures for disassembly and reassembly of the machine, check and maintenance procedures, maintenance reference values, troubleshooting and outline specifications, etc. Please use this Takeuchi manual for Loader TL240 as a reference in service activities to improve maintenance techniques. Please note that the contents and diagrams included in this manual may not match your machine exactly. Items or diagram which manual contains are subject to change without notice due to design modifications, etc. Always store the Takeuchi Loader manual near at hand preferably on the machine itself. When transferring ownership of this machine, be sure to provide the owner manual to the next owner. Table of Content of TL240 Instructions Manual: I . GENERAL II . SPECIFICATIONS III. MACHINE CONFIGURATION IV. HYDRAULIC UNITS V . TROUBLESHOOTING VI. ENGINE Before operating, perform the prescribe inspections and make repairs immediately should any irregularities be found. If a failure that causes loss of control such as steering, service brakes or engine occurs, stop the machine motion as quickly as possible, follow the shutdown procedure, and keep machine securely park until the problem is fixed. Extract from the Service Manual: Before adding refrigerant to the system you should study the sight glass while the engine is running and the air conditioner is on. Even if you found a leak during the system inspection and corrected it, you have no way of knowing how much refrigerant has leaked. You will not be able to tell how much refrigerant is in there, but you can see if bubbles are present. Then check the gauges for unusually high or low readings, or a lack of pressure. Following this procedure, and using your knowledge and experience, decide if it is safe and makes sense to add refrigerant in order to make your full performance inspection. You are now ready to add refrigerant to the system. For your safety and to prevent system damage use the following procedure. (See Service Manual)
