Timberjack 608L Feller Buncher Service Repair Manual Workshop Guide

Model: Timberjack 608L Feller Buncher ( S/N: 10BA1017 and up) Type: Feller Buncher Language: English Format: PDF Timberjack 608L Feller Buncher Repair Service Manual – 468 Pages Description Timberjack 608L Manual Table of Content Section 0000 – General 0010 – How to Use This Book 0020 – Section and Group Contents 0030- Foreword and Warranty 0040 – Safety 0050 – Alphabetical Index 0060 – Major Component Locations Section 1000 – Power Unit 1100 – Engine 1110 – Engine Enclosure Door 1200 – Engine Mounted Equipment 1310 – Engine Mounting 1320 – Removal/Installation 1400 – Fuel System – General 1410 – Fuel System 1500 – Cooling System – General 1510 – Cooling System 1511 – Radiator 1700 – Air Intake System – General 1800 – Exhaust System – General 1900 – Miscellaneous – (Horsepower Test) Section 2000 – Hydraulic System 2000 – Hydraulic Circuits 2110 – Main Pump 2120 – Auxiliary Pump 2130 – Pilot Pump 2210 – Drive Motor 2220 – Swing Motor 2410 – Main Control Valves 2420 – Auxiliary Valves 2430 – Pilot Valves 2600 – Brake Hydraulics – General 2700 – HydrauHc Tanks – General 2800 – Cylinders – General 2810 – Cylinders 2910 – Swing/Rotary Manifold 2950 – Hydraulic Cooling Section 3000 – Electrical System 3000 – Electrical Circuits 3111 – Gauges 3120 – Controls ( electrical) 3 I 40 – Senders & Switches 3910 – Electrical Testing Section 4000 – Power Train 4000 – Drive Train 4300 – Braking Systems 43 IO – Brakes 4600 – Planetaries/Final Drives – General 4610 – Planetaries/Final Drives 4800 – Tracks – General 4810 – Tracks 4820 – Idler 4910 – Speed Adjustment Section 5000 – Cab 5500 – Air Conditioner/Heater Systems 5510 – Air Conditioning Section 6000 – Frames and Panels 6510 – Gearbox/Planetary 6520 – Swing Bearing 6530 – Swing Brake 6800 – Undercarriage 6810 – Links Section 9000 – Technical Information 9400 – Tool Lists & Drawings 9500 – Torque Values 9800 – General Machine Specifications 9810 – Fluids and Lubricants 9900 – Miscellaneous To assist the operator in becoming familiar with the many features of this machine, and thereby become proficient in the operation and periodic maintenance procedures, this manual is provided with detailed operating and service instructions as well as safety information and equipment data.Throughout this manual, references are made to the front, rear, left, and right side of the machine. Consider the right side, left side, front, and rear, of the Forwarder from a seated position in the operator's seat with the engine being at the front. Where applicable throughout the text, "Safety Alert" symbols have been used to indicate important safety measures. Read carefully, understand, and follow these instructions to prevent hazardous situations that could lead to risk of personal injury.The instructions and procedures in this manual cover Forwarders with the most commonly used options; therefore pictorial presentation in some areas may vary slightly from the actual machine. This variation, however, does not have any impact on the accuracy of the written information. The information contained in this manual is current at the time of publication; however, continuing product improvement may result in changes to the machine which are not covered. Should information regarding such changes or further information on the machine be required, please contact your Timberjack dealer .
