Toyota 8FGU15, 8FGU18, 8FGU20, 8FGU25, 8FGU30, 8FGU32 Forklift Repair Manual Workshop Guide

Format: PDF Language: English Model Covered: 8FGU15, 8FGU18, 8FGU20, 8FGU25, 8FGU30, 8FGU32 TOYOTA 8FGU15, 8FGU18, 8FGU20, 8FGU25, 8FGU30, 8FGU32 Forklift Repair Manual – 1389 Pages & 1867 Pages Supplement Manual (above models as of April 2010) – 227 Pages Parts Catalog – 166 Pages 4Y model Engine Manual – 250 Pages 4Y-E Engine Manual – 104 Pages 1DZ-II Engine Manual – 196 Pages Description TOYOTA 8FGU15, 8FGU18, 8FGU20, 8FGU25, 8FGU30, 8FGU32 Forklift Repair Manual Format: PDF Language: English Model Covered: 8FGU15, 8FGU18, 8FGU20, 8FGU25, 8FGU30, 8FGU32 TOYOTA 8FGU15, 8FGU18, 8FGU20, 8FGU25, 8FGU30, 8FGU32 Forklift Repair Manual – 1389 Pages & 1867 Pages Supplement Manual (above models as of April 2010) – 227 Pages Parts Catalog – 166 Pages 4Y model Engine Manual – 250 Pages 4Y-E Engine Manual – 104 Pages 1DZ-II Engine Manual – 196 Pages This manual covers the service procedures of the TOYOTA FORKLIFT 8FGU15 – 32 series. Please use this manual for providing quick, correct servicing of the corresponding forklift model;. This manual deals with the models realease for this forklift even those after April 2010. Please under-stand that disagreement can take place between the descriptions in the manual and actual vehicles due to change in design and specifications. Any change or modifications thereafter will be informed by Toyota Industrial Equipment Parts & Service News. For the service procedures of the mounted engine, read the repair manuals listed below as reference together with this manual. Table of content of the Repair Service Manual GENERAL ENGINE – CHASSIS 4Y-E REPAIR 1DZ-II REPAIR 4Y-E LPG DEVICE REPAIR TRANSMISSION (Pn1•2•3 / Cu2•3) TRANSMISSION (Cu1 Ton Series) PROPELLER SHAFT DIFFERENTIAL FRONT AXLE REAR AXLE STEERING BRAKE BODY MATERIAL HANDLING SYSTEM MAST CYLINDER OIL PUMP OIL CONTROL VALVE MINI LEVER – JOYSTICK SAS / OPS SSTLIST – SERVICE STANDARDS LIST MULTIFUNCTION DISPLAY DX (OPTIONAL) ELECTRICAL SYSTEM TROUBLESHOOTING [except Cu1] ELECTRICAL SYSTEM TROUBLESHOOTING [Cu1 ton series] WIRING DIAGRAM SERVICE INFORMATION BULLETINS OPERATIONAL TIPS 2. Tactful operation (1) Prepare the mechanic tools, necessary measuring instruments (circuit tester, megger, oil pressure gauge, etc.) and SSTs before starting operation. (2) Before disconnecting wiring, always check the cable color and wiring state. (3) When overhauling functional parts, complicated portions or related mechanisms, arrange the parts neatly to prevent confusion. (4) When disassembling and inspecting such a precision part as the control valve, use clean tools and operate in a clean location. (5) Follow the described procedures for disassembly, inspection and reassembly. (6) Replace, gaskets, packings and O-rings with new ones each time they are disassembled. (7) Use genuine Toyota parts for replacement. (8) Use specified bolts and nuts. Observe the specified tightening torque at the time of reassembly. (Tighten to the center of the specified tightening torque range.) If no tightening torque is specified, tighten the bolt or nut according to the standard tightening torque table.
