TOYOTA ALPHARD / VELLFIRE ANH20 / GGH20 (2008-2015) SYSTEMS WIRING DIAGRAMS + CONNECTORS + RELAY + WIRE ROUTING IN PDF FORMAT (1250 PAGES) SUPPLIED BOTH AS DOWNLOADABLE LINK AND PEN DRIVE SHIPPED.
Complete wiring diagram for Toyota Alphard/Vellfire covering engine 2AZ-FE/2GR-FE. This manuals include:
- System wiring diagrams
- Connectors
- Relay location
- Wire routing
POWERTRAIN
Engine
2.5 L 2AZ-FE I4
3.5 L 2GR-FE V6
Transmission
6-speed ATF U660E automatic
7-speed super CVT-i automatic
