TOYOTA RAV4 XA50 XA50 HEV (2018+) SERVICE WORKSHOP MANUAL IN PDF format (
42322 pages
) +
Toyota GSIC online manual
supplied as a downloadable link.
This comprehensive service workshop manual is tailored for the Toyota RAV4 XA50 and XA50 HEV, covering models from 2018 and onwards. Packed with detailed information, it's a vital resource for anyone looking to maintain or repair their RAV4.
ENGINE FEATURED IN THIS MANUAL: 2.0 L M20A-FKS I4 & 2.5L A25A-FXS I4
REFERENCE POWERTRAIN
Engine:
Petrol :
2.0 L M20A-FKS I4
2.5 L A25A-FKS I4
Petrol Hybrid: 2.5 L A25A-FXS I4
Petrol Plug-in Hybrid (PHEV):2.5 L A25A-FXS I4
Electric Motor: Permanent magnet synchronous motors with various configurations.
Power Output:
126 kW (169 hp) for 2.0 L engines
151 kW (202 hp) for 2.5 L engines
163 kW (219 hp) for hybrid (combined)
225 kW (302 hp) for PHEV (combined)
Transmission:
6-speed manual
8-speed AWF8F35/UA80E "Direct Shift" automatic
K120 CVT with physical first gear
Aisin Seiki T110 eCVT with sequential shift mode (hybrid)
Hybrid Drivetrain:
Power-split for hybrid models
PHEV system for plug-in hybrids
Plug-in Charging Features:
6.6 kW AC for Prime models
V2L: 1.5 kW capability for Prime models
