Volvo EC160B NLC Excavator Repair Service Manual Workshop Guide

Manual Included: Repair Service Manual: 1481 Pages Specifications: Brand: Volvo Model: EC160B NLC Type: Excavator Manuals: Repair Service Manual Publication Numbers: Ref. No 485610 1881 Language: English Format: PDF Description Table of Content EC160B NLC Service Information GENERAL DESCRIPTION, COMPLETE MACHINE General SPECIFICATIONS STANDARD TIME TOOL MISCELLANEOUS Service instruction; safety instruction STANDARD PARTS, SERVICE LUBRICANT; FUEL; OTHER FLUID SERVICE Arrival inspections; delivery service Maintenance Condition test Emergency measures Jump starting Safety equipment, without own function group ENGINE WITH MOUNTING AND EQUIPMENT General, engine installation and its function ENGINE General, common info about 211 – 218 Cylinder head Cylinder liner; piston Valve mechanism Crank shaft; connecting rod; vibration damper; fly wheel Engine mounting LUBRICATING SYSTEM General, common info about 221 – 224 FUEL SYSTEM General (common info about 233 – 238) Fuel tank; fuel filling pump INLET SYSTEM; EXHAUST SYSTEM General, common info about 251 – 258 Charge air cooler with connections COOLING SYSTEM General, common info about 261 – 269 Miscelaneous Coolant heater, engine heater ENGINE CONTROL General, common info about 272 – 277 Speed control ELEC. SYSTEM; WARNING SYSTEM; INFORMATION SYSTEM; INSTRUMENTS Comprehensive info, electrical system Software documents, complete vehicle Faulttracing Error codes; checking components BATTERY; ENERGY STORAGE SYSTEM; MOUNTING PARTS General, common info about 311 – 313 Battery ALTERNATOR; CHARGING; ELECTRIC MOTOR; ELECTRIC DRIVES General, common info about 321 – 322 Alternator inclusive drive STARTING SYSTEM General, common info about 331 – 334 Starter motor inclusive solenoid Electric air pre-heater, excluding element LIGHTING General, common info about 351 – 356 OTHER ELECTRICAL EQUIPMENT Audible warning from horn; mounting Horn Audible back-up warning; audible motion warning Back-up warning; travel warning Cleaner Windscreen wiper Switch; connector Switch Automatic control/blocking function, lacking a function group of its own CABLE; FUSE; RELAY General, common info about 371 – 379 Electrical distribution box; fuse box; junction box Fuse Relay Miscellaneous INSTRUMENT; SENSOR; WARNING AND INFORMATION SYSTEM Sender, monitoring system Warning/information unit, display unit Radio, with tape or CD player; voltage divider Radio, with tape or CD player Voltage divider POWER TRANSMISSION GEARBOX, Gearbox Track gearbox, crawler machine Swing gearbox + swing pinion shaft HYDROSTATIC DRIVE Hydraulic motor incl. operating system. Hydraulic motor 1, traveling Hydraulic motor, swing of superstructure Hydraulic pump incl.coupling, travelling incl. operating system Centre passage; lines Centre passage Swing system upper part FRAME; SPRINGS; DAMPING; AXLE SUSPENSION; WHEEL/TRACK UNIT Comprehensive info about frame and track unit/wheels FRAME General, common info about 711 – 718 Counterweight Frame, excavator Undercarriage (crawler machine) WHEELS; TRACKS; TYRE; HUB; DRUM Crawler unit Front idler, incl. fork Sprocket Steel track Top rollers; skid rails Bottom rollers Spring pakage; adjusting cylinder MACHINERY HOUSE; CAB; EXTERIOR TRIM PARTS ANYWHERE CAB, NAKED; CANOPY CAB INTERIOR/UPHOLSTERY Driver's seat, complete; instructor's seat seat, Driver's AIR CONDITIONING UNIT General, common info about 872 – 877 Heating unit Cooling unit Auxiliary heater, diesel fuel operated HYDRAULIC SYSTEM; DIGGING/ HANDLING/ GRADING EQUIPM.; MISC. EQUIP. WORKING HYDRAULICS; SERVO HYDRAULICS General, common info about 911 – 917 Tank; line; oil cooling; filter; breather; filling pump Tank Line; fitting; connecting block; retainer Working hydraulics Directional valve; control valve Hydraulic lock; line rupture valve Pump, working hydraulics Servo hydraulic system Pump Pressure accumulator Control pressure valve, except brake valve Solenoid valve, on/off function Other hydraulic equipment Hydraulics mounted on machine for attachments MECHANICAL EQUIPMENT/ATTACHMENT Attachment bracket, mechanical and hydraulic Quickfit Bucket, incl. possible cylinders with tubes and hoses Dozer equipment, snow equipment UNIT, DIGGING General, common info about 971 – 975 Boom with links Boom Cylinder, boom lifting Dipper arm with links Dipper arm Links; link system Cylinder, dipper arm Cylinder, bucket
