Volvo EC160E NL Excavator Repair Service Manual Workshop Guide

Manual Included: Repair Service Manual: 3032 Pages Specifications: Brand: Volvo Model: EC160E NL Type: Excavator Manuals: Repair Service Manual Publication Numbers: Ref. No 562363 5166 Language: English Format: PDF Description Table of Content EC160E NL Service Information GENERAL DESCRIPTION, COMPLETE MACHINE General SPECIFICATIONS STANDARD TIME TOOL MISCELLANEOUS Service instruction; safety instruction STANDARD PARTS, SERVICE LUBRICANT; FUEL; OTHER FLUID SERVICE General, common info about 171 – 179 Arrival inspections; delivery service Maintenance Condition test Safety equipment, without own function group ENGINE WITH MOUNTING AND EQUIPMENT General, engine installation and its function ENGINE General, common info about 211 – 218 Cylinder block with crankcase ventilation Valve mechanism Crank shaft; connecting rod; vibration damper; fly wheel Oil sump, dipstick incl. LUBRICATING SYSTEM General, common info about 221 – 224 Oil pump; line Oil cooler FUEL SYSTEM General (common info about 233 – 238) Fuel pump; filter; strainer Fuel lines Injector; delivery pipe INLET SYSTEM; EXHAUST SYSTEM General, common info about 251 – 258 Silencer; exhaust pipe Catalytic converter; exhaust emission control equipment Turbo charger Charge air cooler with connections COOLING SYSTEM General, common info about 261 – 269 Radiator, mounting and connections included Coolant pump; thermostat Fan; fan shroud; fan coupling ENGINE CONTROL General, common info about 272 – 277 Miscellaneous EGR (Exhaust Gas Recirculation) ELEC. SYSTEM; WARNING SYSTEM; INFORMATION SYSTEM; INSTRUMENTS Comprehensive info, electrical system Software documents, complete vehicle Faulttracing BATTERY; ENERGY STORAGE SYSTEM; MOUNTING PARTS General, common info about 311 – 313 Battery ALTERNATOR; CHARGING; ELECTRIC MOTOR; ELECTRIC DRIVES General, common info about 321 – 322 Alternator inclusive drive STARTING SYSTEM General, common info about 331 – 334 Starter motor inclusive solenoid Electric air pre-heater, excluding element Starter lock LIGHTING General, common info about 351 – 356 Lighting, extra, including working lighting OTHER ELECTRICAL EQUIPMENT General, common info about 361 – 367 Audible warning from horn; mounting Horn Audible back-up warning; audible motion warning Back-up warning; travel warning Cleaner Windscreen wiper Switch; connector Switch Automatic control/blocking function, lacking a function group of its own CABLE; FUSE; RELAY General, common info about 371 – 379 Cable; battery disconnector Electrical distribution box; fuse box; junction box Electrical distribution box Relay INSTRUMENT; SENSOR; WARNING AND INFORMATION SYSTEM General, common info about 383 – 387 Speedometer; trip meter; hour counter Sender, monitoring system Warning/information unit, display unit Radio, with tape or CD player; voltage divider Radio, with tape or CD player Voltage divider Radio equipment for communication Telematics systems POWER TRANSMISSION General, common info about 410 – 436 GEARBOX, Gearbox Track gearbox, crawler machine Swing gearbox + swing pinion shaft HYDROSTATIC DRIVE Hydraulic motor incl. operating system. Hydraulic motor 1, traveling Hydraulic motor, swing of superstructure Hydraulic pump incl.coupling, travelling incl. operating system Centre passage; lines Centre passage Swing system upper part FRAME; SPRINGS; DAMPING; AXLE SUSPENSION; WHEEL/TRACK UNIT Comprehensive info about frame and track unit/wheels FRAME General, common info about 711 – 718 Protection; belly plate; bumper Counterweight Frame, excavator Undercarriage (crawler machine) WHEELS; TRACKS; TYRE; HUB; DRUM Crawler unit Front idler, incl. fork Sprocket Steel track Top rollers; skid rails Bottom rollers Track support, chain guide (derailing protection) Spring pakage; adjusting cylinder MACHINERY HOUSE; CAB; EXTERIOR TRIM PARTS ANYWHERE Comprehensive info, machinery house and cab CAB, NAKED; CANOPY Cab mounting DOORS; HATCH; COVER PLATE, (all) Door, complete with catch, hinges (no glass) TRIM PART, OUTSIDE; GLASS; SEALING MOULDING Glass; sealing moulding CAB INTERIOR/UPHOLSTERY Driver's seat, complete; instructor's seat AIR CONDITIONING UNIT General, common info about 872 – 877 Air distribution incl. air intake with filter Heating unit Cooling unit Auxiliary heater, diesel fuel operated INTERIOR EQUIPMENT Instrument panel/console; control panel/console/-pedestal Seat belt; other restraining system HYDRAULIC SYSTEM; DIGGING/ HANDLING/ GRADING EQUIPM.; MISC. EQUIP. WORKING HYDRAULICS; SERVO HYDRAULICS General, common info about 911 – 917 Tank; line; oil cooling; filter; breather; filling pump Tank Line; fitting; connecting block; retainer Oil cooling system Working hydraulics Directional valve; control valve Hydraulic lock; line rupture valve Pump, working hydraulics Servo hydraulic system Pump Pressure accumulator Control pressure valve, except brake valve Solenoid valve, on/off function Other hydraulic equipment Hydraulics mounted on machine for attachments MECHANICAL EQUIPMENT/ATTACHMENT Attachment bracket, mechanical and hydraulic Quickfit Bucket, incl. possible cylinders with tubes and hoses Dozer equipment, snow equipment UNIT, DIGGING General, common info about 971 – 975 Boom with links Boom Cylinder, boom lifting Dipper arm with links Dipper arm Links; link system Cylinder, dipper arm Cylinder, bucket
