Yanmar 3TNM74F, 3TNV74F, 3TNV80F Engines Repair Service Manual Workshop Guide

Engine Manual Applicable for 3TNM74F, 3TNV74F, 3TNV80F Manual Code: 0BTN4-EN0031 1st edition English September 2015 Yanmar 3TNM74F, 3TNV74F, 3TNV80F Engines Repair Service Manual – 252 Pages Description Yanmar 3TNM74F, 3TNV74F,3TNV80F Engines Service Manual Engine Manual Applicable for 3TNM74F, 3TNV74F, 3TNV80F Manual Code: 0BTN4-EN0031 1st edition English September 2015 Yanmar 3TNM74F, 3TNV74F, 3TNV80F Engines Repair Service Manual – 252 Pages TABLE OF CONTENTS Introduction Safety General Service Information Periodic Maintenance Engine Fuel System Cooling System Lubrication System Starter Motor Alternator Electric Wiring Troubleshooting This Service Manual has been developed for the exclusive use of service and repair professionals such as YANMAR. This Service Manual describes the service procedures for the TNM and TNV series indirect injection engines. These engines are certified by the U.S. EPA, California ARB and/or the 97/68/EC Directive for industrial use. Please use this manual for accurate, quick and safe servicing of the engine. Since the directions in this manual are for a typical engine, some specifications and components may be different from your engine.
